CHAFON CF6D2 Prime UHF RFID Integrated Reader, 865-867 MHz, 12 dBi Antenna, TCP/IP, IP65, 0-15 m Range
The CHAFON CF6D2 Prime is a high-performance UHF RFID integrated reader module operating at 865-867 MHz (EU) with a built-in 12 dBi antenna for a reading range of up to 15 meters. It features TCP/IP, RS232, and relay interfaces for seamless integration into industrial automation, asset tracking, and access control systems.
Features
- Integrated 12 dBi antenna provides a long reading range of up to 15 meters.
- Multi-protocol communication via TCP/IP, RS232, and relay outputs for flexible system integration.
- IP65-rated ABS and die-cast aluminum enclosure ensures durability in harsh indoor/outdoor environments.
- Adjustable RF output power (0-26 dBm) for optimized performance and compliance.
- Supports ISO18000-6C (EPC GEN2) protocol for global UHF RFID tag compatibility.
Out of stock
The CHAFON CF6D2 Prime UHF RFID Reader is engineered for reliable, long-range identification and data collection. Utilizing circular polarization in its integrated antenna design, it ensures consistent tag reads regardless of orientation. The reader’s robust signal processing and adjustable RF power allow for precise control over the interrogation zone, making it suitable for dense tag environments.
Built with an IP65-rated housing combining ABS plastic and die-cast aluminum, the module is protected against dust ingress and water jets, supporting operation in temperatures from -10°C to +55°C. Its integrated interfaces, including TCP/IP for network connectivity and RS232 for serial communication, enable direct integration with PLCs, industrial PCs, and custom embedded systems for real-time asset management and logistics automation.
Additional Information
| Weight | 3.1 kg |
|---|---|
| Dimensions | 41.5 × 41.5 × 6.7 cm |
