Intel Intel RealSense Depth Camera D555 w/ PoE & Global Shutter

The D555 is fully compatible with Intel Intel RealSense SDK 2.0 (librealsense) for Windows, Linux, and embedded platforms, providing APIs for depth stream configuration, point cloud generation, and sensor control. For robotics, it offers native ROS 2 support via the SafeDDS middleware, allowing direct integration into robotic operating systems for real-time perception pipelines. Developers can also utilize OpenCV and PyTorch for custom computer vision and machine learning applications.

You can power the D555 via its RJ45 port using a standard IEEE 802.3af-compliant Power over Ethernet (PoE) injector or switch, which simplifies cabling by combining data and up to 5.5W power delivery. Alternatively, you can use the USB-C port for both data and 5V power, though this may limit cable length. For network setup, assign a static IP or use DHCP, then connect via Ethernet for low-latency streaming or USB for direct host communication.

The D555 introduces the new Vision SoC V5, offering improved depth processing efficiency and lower latency compared to the host-based processing of older models. It features a global shutter RGB sensor (unlike the rolling shutter in the D435) for distortion-free imaging of fast-moving objects. The integrated IMU and IP65-rated industrial enclosure are significant upgrades, making the D555 suitable for dynamic, outdoor, or harsh environment applications where the D435 was more limited.

Yes, the D555 is designed for challenging environments with its IP65 rating, meaning it is dust-tight and protected against low-pressure water jets from any direction. Its operating temperature range of -20°C to +50°C allows deployment in both cold and hot outdoor settings. However, for prolonged direct rain or submersion, additional external housing is recommended, and the PoE connection should use outdoor-rated, shielded Ethernet cables for optimal reliability.
