Teledyne FLIR ONE Pro Thermal Imaging Camera for iPhone iOS
The Teledyne FLIR ONE Pro is a professional-grade thermal imaging camera accessory for iPhone, featuring a 160 x 120 thermal sensor with Teledyne FLIR VividIR™ processing for detecting temperature differences down to 70 mK and measuring up to 400°C.
Features
- High-resolution thermal imaging with 160 x 120 IR sensor and Teledyne FLIR VividIRâ„¢ for enhanced image clarity.
- Extended temperature measurement range from -20°C to 400°C, ideal for industrial diagnostics.
- Integrated visual camera with 1440 x 1080 resolution and MSX® technology for overlaying thermal and visual data.
- Designed for iOS with a Lightning connector, powered by a built-in battery offering ~1 hour of operation.
- Includes the Teledyne FLIR ONE mobile app for spot meters, automated reporting, and professional analysis tools.
Out of stock
The Teledyne FLIR ONE Pro transforms your iPhone into a powerful thermal diagnostic tool, engineered for professional inspections and troubleshooting. It integrates a high-sensitivity microbolometer thermal sensor with a spectral range of 8-14 µm, capable of detecting subtle temperature variations as low as 70 mK. The camera employs Teledyne FLIR’s proprietary VividIRâ„¢ image processing and MSX® (Multi-Spectral Dynamic Imaging) to deliver sharp, detailed thermal visuals overlaid with visual camera outlines for precise problem location.
Built for field use, the device features a robust, compact form factor with a fixed focus from 15 cm to infinity and an adjustable OneFit connector for secure iPhone attachment. It supports radiometric JPEG stills and MP4 video capture, enabling thorough documentation of electrical, mechanical, HVAC, or building envelope issues directly from the iOS app with integrated reporting workflows.
Additional Information
| Weight | 0.0365 kg |
|---|---|
| Dimensions | 6.8 × 3.4 cm |
