Pro-Range E38H8G5-1000L-15T Rotary Incremental Encoder - 38mm, Photoelectric, ABZ 3 Channels, 1000 PPR
The Pro-Range E38H8G5-1000L-15T is a 38mm photoelectric rotary incremental encoder delivering 1000 PPR resolution with ABZ 3-channel output. Operating from a 5-24V DC supply, it provides precise quadrature and index signals for integration with PLCs, industrial drives, and motion control systems.
Features
- High-resolution 1000 pulses per revolution (PPR) for accurate angular position feedback.
- ABZ 3-channel output (quadrature A/B and index Z) for direction sensing and homing.
- Wide operating voltage range of 5-24V DC for compatibility with industrial PLCs and controllers.
- Compact 38mm diameter photoelectric design for reliable performance in space-constrained installations.
- Robust construction ensures durability for demanding motion control and automation applications.
Out of stock
The Pro-Range E38H8G5-1000L-15T incremental encoder utilizes an infrared LED light source and a phototransistor array to generate precise digital pulses as the shaft rotates. This photoelectric sensing principle provides high immunity to electrical noise and ensures long-term signal stability. The quadrature A and B channels allow for direction detection and increased resolution via 4x decoding, while the Z-channel index pulse provides a single reference mark per revolution for absolute position initialization.
Built for industrial environments, the encoder features a durable housing designed to withstand mechanical vibration and contamination. Its 38mm mounting footprint and standard shaft interface facilitate easy integration into servo motors, conveyor systems, and rotary tables. The wide 5-24V DC input range ensures direct compatibility with a broad spectrum of industrial automation hardware without requiring additional signal conditioning.
Additional Information
| Weight | 0.95 kg |
|---|---|
| Dimensions | 9 × 9 × 7 cm |
