Moresense MSWXB2522 WiFi 6 Combo Module 2.4GHz & 5GHz w/ BLE 5.2

₹369.00 (Inclusive of all taxes)
Out of Stock

The Moresense MSWXB2522 is a low-power embedded Wi-Fi 6 combo module supporting dual-band 2.4GHz/5GHz Wi-Fi and Bluetooth Low Energy 5.2, designed to provide UART-based IoT devices with high-efficiency wireless connectivity for cloud platforms and local networks.

Features

  • Wi-Fi 6 (802.11ax) & BLE 5.2 Combo: Integrates advanced dual-band Wi-Fi for faster, more efficient data transfer alongside Bluetooth Low Energy for versatile network topologies and low-power peripheral connections.
  • Ultra-Low Power Embedded Architecture: Features industry-leading power optimization for low-traffic, low-frequency IoT applications like smart sensors, healthcare devices, and industrial telemetry.
  • Built-In High-Performance Antenna: Includes an integrated antenna for reliable signal reception and stable wireless links, simplifying PCB design and reducing BOM cost.
  • Comprehensive Cloud & Protocol Support: Firmware supports TCP/IP stack and is compatible with major IoT clouds including Amazon AWS, Alibaba Cloud, and Tencent IoT for seamless integration.
  • UART Host Interface: Provides a simple serial (UART) interface, allowing traditional MCU-controlled devices to easily connect to Wi-Fi networks for remote control and data transfer.

Out of stock

Description

The MSWXB2522 WiFi 6 Combo Module from Moresense is a fully integrated wireless solution combining 2.4GHz and 5GHz Wi-Fi 6 (802.11ax) with Bluetooth Low Energy 5.2 in a compact 25mm x 22mm form factor. Its hardware integrates MAC, baseband, RF transceiver, and power amplifier, offering a complete RF front-end. The embedded firmware manages Wi-Fi protocols, network configuration, and a full TCP/IP stack, enabling legacy UART-based devices or microcontroller systems to achieve robust, cloud-ready wireless connectivity with minimal development overhead.

Engineered for IoT edge nodes, the module employs a low-power architecture specifically optimized for intermittent, small-packet data transmission common in smart home automation, personal healthcare monitors, smart grid sensors, and industrial control systems. Its support for both Station and Access Point modes, coupled with BLE, allows for flexible network deployment and device provisioning. The module’s compatibility with leading public and private IoT clouds facilitates rapid deployment into existing managed ecosystems.

Key Features

  • Dual-Band Wi-Fi 6 (802.11ax): Delivers higher data rates, increased capacity, and improved power efficiency over 2.4GHz and 5GHz bands compared to legacy Wi-Fi 4/5.
  • Bluetooth Low Energy 5.2: Enables energy-efficient peripheral communication, beaconing, and mesh networking for complementary wireless functionality.
  • Optimized for Low-Traffic IoT: Features specialized firmware and hardware design to minimize power consumption during idle and active states, extending battery life in sensor applications.
  • Integrated RF Front-End: Contains on-module power amplifier, matching network, and built-in antenna for simplified design-in and reduced time-to-market.
  • UART Host Control Interface: Allows a host microcontroller to communicate with the module via simple AT commands or proprietary protocols for data transmission and network management.
  • Extensive Cloud Ecosystem Compatibility: Pre-integrated support for Amazon Web Services (AWS), Alibaba Cloud IoT, Tencent IoT, and private cloud deployments.
  • Compact SMT Package: The 25x22mm LGA form factor is designed for surface-mount assembly, saving space in end-product designs.

Applications

  • Smart Home & Building Automation: Connects lighting controls, thermostats, security sensors, and smart plugs to Wi-Fi networks for remote management via cloud apps.
  • Industrial IoT (IIoT) & Telemetry: Enables wireless data collection from sensors monitoring temperature, vibration, or energy consumption in factory and utility environments.
  • Personal Healthcare & Wearable Devices: Provides low-power connectivity for health monitors, fitness trackers, and medical sensors to upload data to cloud dashboards.
  • Smart Grid & Energy Management: Facilitates communication for smart meters, distribution automation devices, and renewable energy monitoring systems.
  • Consumer Electronics & Handheld Devices: Adds Wi-Fi and BLE connectivity to remote controls, toys, and portable instrumentation.

Technical Specifications

Wireless ProtocolsWi-Fi 6 (802.11b/g/n/ax), Bluetooth Low Energy 5.2
Frequency Range2.4GHz & 5GHz Dual-Band
Host InterfaceUART
Module Dimensions25mm x 22mm (L x W)
AntennaIntegrated Built-In Antenna
SRAM992KB
Typical ApplicationsSmart Home, Industrial Control, Healthcare, Smart Grid

Frequently Asked Questions

What is the primary host interface for the MSWXB2522 module, and how do I communicate with it?

The primary host interface is a UART (Serial) connection. You communicate with the module by sending AT commands over this serial link from your main microcontroller or processor. The baud rate is typically configurable (e.g., 115200 bps). You use these commands to join Wi-Fi networks, configure the module as a Station or Access Point, establish TCP/UDP connections, and transfer data to and from your cloud server or local network.

Does the MSWXB2522 support both Wi-Fi client (STA) and Access Point (AP) modes simultaneously?

Yes, the MSWXB2522 firmware supports standard Wi-Fi operating modes including Station (STA) mode to connect to an existing router, Access Point (AP) mode to create its own network, and a combined STA+AP mode. This flexibility is useful for device provisioning, where the module acts as an AP for initial configuration via a smartphone before connecting as a STA to your home Wi-Fi. The specific mode is selected and controlled via the AT command set provided with the module.

How do I integrate the MSWXB2522 with cloud platforms like AWS IoT or Alibaba Cloud?

Integration is handled through the module's firmware and your host MCU code. The module manages the Wi-Fi connection and TCP/IP stack. Your host MCU sends data via UART, and the module forwards it via MQTT or HTTP(S) protocols to the cloud endpoint. You typically need to configure the cloud server's address, port, and security credentials (client ID, certificates) using specific AT commands. The module's documentation will provide the exact command set for connecting to supported cloud services.

What is the power supply requirement for the MSWXB2522 module during operation?

The module requires a regulated 3.3V DC power supply. You must consult the official datasheet for precise current consumption figures, but as a low-power Wi-Fi 6 module, it will have specific active transmit/receive currents and much lower sleep currents. Proper power supply design with adequate decoupling capacitors near the module's power pins is critical for stable RF performance and to prevent voltage drops during high-power transmission bursts.

Can I develop custom firmware for the MSWXB2522, or is it a closed AT-command module?

The MSWXB2522 is primarily designed as a host-controlled module using its built-in AT command firmware. This means you typically do not flash custom code onto the module itself; instead, you develop software on your external host MCU that sends commands to it. However, the vendor may offer an SDK for advanced users to develop custom firmware, but this depends on the chipset used and Moresense's support policy. For most applications, the provided AT command set is sufficient for IoT connectivity.

Package Includes

  • 1 x Moresense MSWXB2522 WiFi 6 Combo Module

Additional Information

Weight 0.05 kg
Dimensions 6 × 6 × 2 cm
