Mamba F405 Flight Controller & REV35 35A BLheli_S 2-6S 4 In 1 ESC Stack
The Mamba F405 Flight Controller paired with the REV35 35A 4-in-1 ESC provides a compact, integrated power system for 3-6S FPV drones, featuring an STM32F405 MCU, MPU6000 gyro, and BLHeli_S firmware for Betaflight compatibility.
Features
- Integrated F405 Flight Controller with MPU6000 gyro and 16MB flash memory.
- REV35 4-in-1 ESC delivers 35A continuous (40A peak) per channel for 2-6S LiPo batteries.
- Compact 36x36mm stack with 30.5×30.5mm M3 mounting for standard 5-inch frames.
- Features a built-in current sensor and a 5V/1.5A BEC for peripheral power.
- Supports DShot600, OneShot, MultiShot, and PWM protocols out of the box.
Out of stock
The Mamba F405 & REV35 stack combines a high-performance flight controller with a robust 4-in-1 ESC in a single, space-saving unit. The STM32F405 microcontroller provides ample processing power for Betaflight, while the integrated MPU6000 IMU ensures stable flight characteristics. This design eliminates the need for separate wiring between the FC and ESC, simplifying builds and reducing points of failure.
The REV35 ESCs utilize BLHeli_S firmware on BB21 MCUs, offering smooth throttle response and support for modern digital protocols like DShot600. The stack’s compact 36x36mm footprint with 30.5×30.5mm mounting holes makes it a direct fit for a wide range of 5-inch FPV quadcopter frames. Its built-in 5V BEC and current sensor provide essential power and telemetry data without requiring additional modules.
Additional Information
| Weight | 0.06 kg |
|---|---|
| Dimensions | 4.5 × 4.4 cm |
