Waveshare Long-wave IR Thermal Imaging Camera HAT (B) for Raspberry Pi, 45° FOV, 80×62 Pixels
The Waveshare Thermal Imaging Camera HAT (B) is a long-wave infrared (LWIR) sensor module for Raspberry Pi, providing real-time thermal data capture at up to 25 FPS via the standard 40-pin GPIO header for non-contact temperature measurement and analysis.
Features
- 80×62 pixel hybrid microbolometer+thermopile sensor for accurate thermal imaging.
- Shutterless design enables smooth, uninterrupted thermal video streaming up to 25 FPS.
- Plug-and-play integration with standard 40-pin Raspberry Pi GPIO header.
- Wide operating temperature range from -40°C to 85°C for robust applications.
- Low power consumption, drawing approximately 20mA from a 5V supply.
Out of stock
The Waveshare Long-wave IR Thermal Imaging Camera HAT (B) is a compact thermal sensor module designed for direct integration with Raspberry Pi single-board computers. It utilizes a hybrid sensing architecture combining a microbolometer and thermopile to capture long-wave infrared radiation (8-14μm wavelength) with a resolution of 80×62 pixels. This shutterless design eliminates the need for periodic calibration pauses, enabling continuous thermal video capture at frame rates up to 25 FPS for real-time monitoring applications.
Operating from a 5V supply with low current draw, the module is engineered for reliable performance across an extended temperature range from -40°C to 85°C. It connects seamlessly via the Raspberry Pi’s standard 40-pin GPIO header, requiring no external drivers or complex wiring. The integrated processing provides calibrated pixel data, delivering temperature measurement accuracy within ±1.5°C in ambient conditions, making it a practical tool for developers and system integrators.
Additional Information
| Weight | 0.01 kg |
|---|---|
| Dimensions | 6.5 × 3 cm |
