Waveshare E-Paper Driver Shield (B) for Arduino NUCLEO
The Waveshare Universal E-Paper Raw Panel Driver Shield (B) is a versatile expansion board for Arduino and NUCLEO platforms, simplifying e-paper display integration. It features an onboard MX25R6435F 64M-bit flash chip for image storage and supports flexible 3.3V/5V MCUs via SPI, offering robust graphics processing and expandability.
Features
- Directly compatible with Arduino and NUCLEO host boards.
- Onboard MX25R6435F 64M-bit flash provides ample storage for display data and images.
- Supports both 3-wire and 4-wire SPI communication for versatile e-paper panel control.
- Integrated voltage translator ensures seamless 3.3V/5V MCU compatibility.
- Reserved soldering pads allow for expanding external RAM, enhancing graphics capabilities.
Out of stock
The Waveshare Universal E-Paper Raw Panel Driver Shield (B) offers a streamlined solution for integrating e-paper displays into your Arduino and NUCLEO-based projects. Designed for seamless compatibility, this shield simplifies the complex driving requirements of various e-paper panels through its flexible SPI interface. Its architecture includes an essential onboard MX25R6435F 64M-bit (8MB) serial NOR flash chip, providing dedicated storage for display content, fonts, and graphics data, offloading this burden from the host microcontroller.
This driver shield ensures broad compatibility with both 3.3V and 5V microcontrollers thanks to its integrated voltage translator, making it suitable for a wide array of development boards including popular Arduino UNO, Leonardo, and various STM32 NUCLEO boards. Furthermore, the board includes reserved soldering pads for external RAM expansion, offering developers the flexibility to boost memory capacity for more demanding graphical applications or complex data buffering, thereby enhancing the performance and scope of e-paper projects.
Additional Information
| Weight | 0.027 kg |
|---|---|
| Dimensions | 8 × 7 × 3 cm |
