UBEC 5V 5A BEC Voltage Regulator
This UBEC 5V 5A voltage regulator efficiently converts higher input voltages (2S-8S LiPo) to a stable 5.25V output, providing reliable power for receivers, flight controllers, and servos in FPV drones, RC airplanes, and helicopters. Designed for high-current applications, it ensures consistent power delivery, crucial for sensitive onboard electronics and FPV image transmission systems.
Features
- Wide 2S-8S LiPo input voltage compatibility (5.5V-35V) for versatile drone and RC applications.
- Delivers a stable 5.25V output with a continuous 5A current, handling peak loads up to 6A for 20 seconds.
- Essential for providing dedicated, clean power to receivers, flight controllers, gyroscopes, and multiple servos.
- Specifically optimized for FPV image transmission systems and sensitive electronics, preventing voltage fluctuations.
Out of stock
The UBEC (Universal Battery Eliminator Circuit) serves as an external switching power supply regulator, designed to operate independently of the brushless ESC. It efficiently steps down high input voltages, ranging from 5.5V to 35V (compatible with 2S to 8S LiPo batteries), to a precisely regulated 5.25V DC output. This stability is critical for reliably powering sensitive onboard electronics such as receivers, flight controllers, and various other auxiliary devices, ensuring optimal performance and preventing brownouts.
Capable of supplying a continuous current of 5A, with momentary peaks up to 6A for 20 seconds, this UBEC can effortlessly support demanding power requirements. It is an ideal solution for remote control model helicopters, FPV camera systems, GoPro brushless gimbals, and larger fixed-wing aircraft that utilize high-voltage power systems and multiple high-torque servos. Its robust design is particularly beneficial for applications requiring dedicated, clean power for FPV image transmission, enhancing overall system reliability and signal integrity.
Additional Information
| Dimensions | 5 × 3 × 3 cm |
|---|
