Matek MICRO BEC 5V/12V-ADJ Voltage Regulator
The Matek MICRO BEC 5V/12V-ADJ is a compact and efficient voltage regulator designed for FPV drones and RC quadcopters. It provides a stable, adjustable 5V, 9V, or 12V output from a 7-21V input, ensuring reliable power delivery to critical onboard electronics.
Features
- Delivers stable 5V, 9V, or 12V adjustable output at 1.5A continuous current.
- Wide input voltage range from 7V to 21V (2S-5S LiPo compatible).
- High efficiency (up to 95%) minimizes heat generation and power loss.
- Integrated overheat protection for enhanced component safety and longevity.
Out of stock
The Matek MICRO BEC 5V/12V-ADJ is engineered to provide a robust and clean power supply for various drone components. With its integrated voltage regulator IC, it efficiently steps down higher battery voltages (7-21V) to a user-selectable 5V, 9V, or 12V output. This stability is crucial for sensitive electronics such as flight controllers, FPV cameras, and video transmitters, preventing brownouts and ensuring optimal performance across your multirotor.
Designed for compact integration, this micro BEC boasts a high conversion efficiency of up to 95%, which translates to less heat dissipation and improved system reliability, even under continuous 1.5A load. Its wide operating temperature range from -45°C to 85°C ensures dependable operation in diverse environmental conditions, making it a versatile choice for both recreational FPV pilots and commercial UAV applications.
Additional Information
| Dimensions | 1.7 × 1.1 cm |
|---|
