Meskernel LDL-20 High Accuracy Phase Distance Sensor (Red Visible Laser) - USART/RS232/RS485 Interface
The Meskernel LDL-20 is a high-precision phase-shift laser distance sensor with a visible red laser (610-690 nm), offering a 0.03 to 20m measurement range. It provides flexible communication via USART, RS232, or RS485 interfaces, making it compatible with industrial PLCs, microcontrollers, and data acquisition systems.
Features
- High-precision phase-shift measurement principle for accurate distance sensing up to 20 meters.
- Visible red laser (Class II, <1mW) for easy targeting and alignment during setup.
- Multi-protocol communication support including USART, RS232, and RS485 interfaces.
- Compact and lightweight design for straightforward integration into robotic and automation systems.
- Wide operating temperature range of 0°C to 50°C for reliable performance in industrial environments.
Out of stock
The Meskernel LDL-20 Phase Distance Sensor employs an advanced optical phase-shift principle to deliver highly accurate distance measurements. Its visible red laser emitter operates within the 610-690 nm wavelength, providing a clear visual indicator for precise target alignment, which is critical in automated inspection and positioning tasks.
Engineered for industrial durability, the sensor supports multiple digital communication protocols, including USART, RS232, and RS485, allowing for seamless integration into complex control networks. The compact form factor and robust construction ensure reliable operation in environments such as warehouse logistics, robotic navigation, and safety monitoring systems.
Additional Information
| Weight | 0.04 kg |
|---|---|
| Dimensions | 11 × 14 × 2 cm |
