Matek Systems F405-OSD Flight Controller - BetaFlight OSD, 168MHz STM32F405, ICM-20602 Gyro
The Matek F405-OSD Flight Controller is a feature-rich 36x36mm STM32F405-based board designed for FPV drones, featuring BetaFlight OSD, a 6-axis ICM-20602 gyro, and extensive connectivity including 5 UARTs and 6 DShot outputs for precise motor control.
Features
- 168MHz STM32F405RGT6 processor for high-speed flight control calculations.
- 6-axis ICM-20602 gyro/accelerometer supporting 32K gyro update rates.
- Integrated BetaFlight OSD with AT7456E chip for on-screen telemetry display.
- MicroSD card slot for Blackbox flight data logging and analysis.
- Five UARTs and six PWM/DShot outputs for extensive peripheral connectivity.
Out of stock
The Matek F405-OSD is engineered around the powerful STM32F405 microcontroller, providing the processing headroom needed for modern BetaFlight firmware features and high PID loop rates. Its compact 36x36mm footprint and lightweight design make it suitable for a wide range of 5-inch and smaller FPV racing and freestyle quadcopter builds.
The board includes a dedicated SPI bus for the high-performance ICM-20602 IMU, ensuring low-latency, accurate sensor data. Connectivity is a key strength, with five UARTs available for GPS, telemetry, serial receivers, and other peripherals, alongside built-in support for WS2812 LED strips and an inverter for SBUS input.
Additional Information
| Weight | 0.012 kg |
|---|---|
| Dimensions | 3.6 × 3.6 × 0.7 cm |
