EMAX ECOII-2004-2000KV Brushless Motor
The EMAX ECOII-2004-2000KV brushless motor is engineered for 4-5 inch FPV drones, delivering up to 1130g of thrust on 6S LiPo power. Featuring an upgraded N52SH magnet design and a durable 12x12mm mounting pattern, it provides a high-performance, smooth-running powerplant for freestyle and racing builds.
Features
- 2000KV rating optimized for 4-5 inch propellers on 4S-6S LiPo batteries.
- Upgraded N52SH curved arc magnets for increased torque, tighter airgap, and higher RPM performance.
- Reinforced rounded bell design with a mirror-polished finish for enhanced durability and reduced weight (16.6g).
- Precision NSK bearings ensure smooth, reliable operation and extended motor life.
- Standard 12x12mm motor mounting pattern for compatibility with a wide range of FPV frames.
Out of stock
The EMAX ECOII-2004-2000KV brushless motor represents a significant evolution in the ECO series, built from the ground up for superior durability and flight performance. Its all-new architecture incorporates thicker reinforcements and a rounded bell design to withstand the impacts common in FPV racing and freestyle flying. The reflective, mirror-polished surface is not only aesthetically pleasing but also contributes to the motor’s robust construction.
Internally, the motor leverages a 12N14P framework and high-grade N52SH magnets, replacing the previous N48 type. This upgrade translates directly into a more powerful throttle response, higher achievable RPMs, and greater thrust output—up to 1130 grams on a 6S LiPo. The result is a motor that provides pilots with the torque and headroom needed for aggressive maneuvers and consistent lap times.
Additional Information
| Weight | 0.036 kg |
|---|---|
| Dimensions | 7 × 4 × 2 cm |
