CAPUF WCH CH32V003 Programmer/Debugger
CAPUF WCH CH32V003 Programmer/Debugger - Image 2
SKU: SBCD-0787
📋 GST Invoice Available

CAPUF WCH CH32V003 Programmer/Debugger

₹869.00 (Inclusive of all taxes)
Out of Stock

The CAPUF WCH CH32V003 Programmer/Debugger is a versatile tool for online debugging and flashing WCH RISC-V microcontrollers and ARM-based MCUs via SWD/JTAG. It integrates USB-to-TTL serial functionality and provides controllable 3.3V/5V power outputs for target devices.

Features

  • Supports WCH RISC-V and ARM (SWD/JTAG) MCU debugging and downloading.
  • Integrated USB to TTL serial port for communication.
  • Controllable 3.3V/5V power supply outputs for target boards.
  • Features automatic firmware detection and upgrade capability.
  • Includes automatic power-off protection for safe operation.

Out of stock

Description

The WCH-LinkE module, offered by CAPUF, serves as a comprehensive development tool for embedded systems. It facilitates seamless online debugging and program downloading for microcontrollers utilizing the WCH RISC-V architecture, alongside broad compatibility with ARM chips through standard SWD and JTAG interfaces. This adaptability makes it an essential device for developers working across various MCU platforms.

Equipped with a JTAG interface, the WCH-LinkE supports four-wire connections (TMS, TCK, TDI, TDO), enabling extended operations with a computer to control and debug CPU, DSP, FPGA, and CPLD devices. Its high-speed USB 2.0 full-speed interface ensures plug-and-play connectivity with host computers, streamlining the debugging and programming workflow. The module’s robust design and multi-protocol support simplify complex hardware interaction for advanced development tasks.

Key Features

  • Two 3.3V/5V power supply outputs for target devices.
  • Integrated USB to TTL serial port function for communication.
  • Supports RISC-V chip single-wire/dual-wire downloading and debugging.
  • Compatible with ARM kernel MCUs via SWD/JTAG interface for debugging and downloading.
  • Automatic firmware detection and upgrade capabilities ensure up-to-date functionality.
  • 3.3V/5V output power supply is individually controllable.
  • Features automatic power-off protection for enhanced safety.
  • Red and blue LED indicators provide clear operational status feedback.
  • Supports host computer control for switching working modes with one key.

Applications

  • Online debugging and programming of WCH RISC-V microcontrollers.
  • Debugging and flashing ARM-based MCUs using SWD/JTAG interfaces.
  • Interfacing and controlling CPUs, DSPs, FPGAs, and CPLDs via JTAG.
  • Serial communication (USB to TTL) for embedded system development.
  • Firmware development and testing for various embedded platforms.

Technical Specifications

Data bit8
Stop bit1
Checksum bitNone
Flow controlNone
Length75mm
Width24mm
Height15mm

Frequently Asked Questions

What microcontroller architectures does the WCH-LinkE support?

The WCH-LinkE programmer supports WCH's own RISC-V architecture MCUs for single-wire and dual-wire downloading/debugging. It also offers compatibility with a wide range of ARM kernel MCUs through standard SWD (Serial Wire Debug) and JTAG interfaces, making it a versatile tool for diverse embedded projects.

Can this programmer provide power to my target board?

Yes, the WCH-LinkE module features two controllable power supply outputs, providing either 3.3V or 5V. This functionality allows you to power your target development board directly from the programmer, simplifying setup and reducing the need for external power sources during debugging and flashing operations.

What operating modes does the WCH-LinkE module offer?

The module primarily operates as an online debugger/programmer for MCUs and also includes a USB to TTL serial port function. It supports firmware detection and automatic upgrades. A host computer can switch between its debugging and serial communication modes, enhancing its utility for various development tasks.

Is the WCH-LinkE compatible with older JTAG devices like FPGAs or CPLDs?

Yes, beyond MCU support, the WCH-LinkE provides a JTAG interface designed to support four-wire connections (TMS, TCK, TDI, TDO). This enables it to extend a computer's JTAG capabilities to operate and debug a range of devices including CPUs, DSPs, FPGAs, and CPLDs, broadening its application scope.

Package Includes

  • 1 x CAPUF WCH CH32V003 Programmer/Debugger

Additional Information

Weight 0.015 kg
Dimensions 7.5 × 2.4 × 1.5 cm
