Renke RS-YL-PL-2-02-EX Tipping Bucket Rain Gauge - Pulse Output
The Renke RS-YL-PL-2-02-EX is a tipping bucket rain gauge providing 0.2mm resolution rainfall data via a pulse output signal, designed for integration with data loggers, Arduino, Raspberry Pi, and industrial PLC monitoring systems.
Features
- Standard tipping bucket measurement principle with 0.2mm per tip resolution.
- Pulse output signal for direct connection to digital inputs of microcontrollers and data acquisition systems.
- Durable integrated shell construction rated for outdoor operation from 0 to 50°C.
- Compact design with a 200mm diameter collection funnel for accurate area sampling.
- Provides rainfall data with an accuracy of ≤±5% for reliable environmental monitoring.
Out of stock
The Renke RS-YL-PL-2-02-EX tipping bucket rain gauge operates on the established mechanical principle where collected rainwater fills a small bucket, causing it to tip and generate an electrical pulse. Each tip corresponds to a precise volume of rainfall, specifically 0.2mm of precipitation, enabling high-resolution data collection for meteorological analysis.
Engineered for continuous outdoor deployment, the sensor features a robust integrated shell capable of withstanding storage temperatures from -40°C to 125°C and operational temperatures from 0°C to 50°C. Its pulse output provides a simple, digital interface compatible with a wide range of data loggers, programmable logic controllers (PLCs), and microcontroller-based systems like Arduino and Raspberry Pi for automated weather station integration.
Additional Information
| Weight | 0.9 kg |
|---|---|
| Dimensions | 29 × 29 cm |
