SN65HVD230 CAN Bus Transceiver Evaluation Board
This SN65HVD230 CAN Bus transceiver board provides a 3.3V interface for connecting microcontrollers and single-board computers to Controller Area Network (CAN) buses, commonly used in automotive, industrial automation, and robotics applications.
Features
- Integrates the SN65HVD230 CAN transceiver IC for reliable differential bus communication.
- Operates from a single 3.3V power supply, ideal for low-voltage MCUs like ESP32 or STM32.
- Features built-in ESD protection for enhanced robustness in electrically noisy environments.
- Pinout compatible with the industry-standard PCA82C250, ensuring broad hardware compatibility.
- Serves as an essential evaluation module for prototyping CAN network nodes and gateways.
Out of stock
The SN65HVD230 CAN Board is a compact development module centered on the SN65HVD230 transceiver from Texas Instruments. This IC is designed for high-speed CAN applications, providing the necessary physical layer interface to convert logic-level signals from a microcontroller into the differential signals required on a CAN bus. Its 3.3V operation makes it a perfect match for modern low-power microcontrollers and System-on-Chip (SoC) platforms.
The board’s architecture includes necessary termination and filtering components to ensure signal integrity. The built-in Electrostatic Discharge (ESD) protection safeguards the transceiver and the connected host controller from voltage spikes, which is critical for reliability in automotive and industrial settings. This module acts as a foundational building block for engineers and developers creating CAN-based telemetry systems, vehicle data loggers, or industrial machine control networks.
Additional Information
| Weight | 0.02 kg |
|---|---|
| Dimensions | 2 × 4 × 1 cm |
