Waveshare 2-Ch Isolated CAN HAT for Raspberry Pi
This Waveshare 2-Channel Isolated CAN Expansion HAT empowers your Raspberry Pi with robust, isolated CAN bus communication. Featuring a dual-chip MCP2515 and SN65HVD230 solution, it ensures reliable data exchange for industrial and automotive applications while supporting 3.3V/5V logic levels.
Features
- Integrated power and signal isolation enhances communication safety and anti-interference for reliable operation.
- Dual-chip solution (MCP2515 controller, SN65HVD230 transceiver) provides robust 2-channel CAN bus capability.
- Onboard TVS diode offers ESD protection and transient peak voltage suppression, safeguarding your Raspberry Pi.
- Features a selectable 3.3V/5V logic level via jumper and an onboard 120Ω terminal resistor, also jumper-configurable.
Out of stock
The Waveshare 2-Channel Isolated CAN Bus Expansion HAT provides a reliable and secure CAN communication interface for your Raspberry Pi. Utilizing a robust MCP2515 CAN controller and SN65HVD230 CAN transceiver dual-chip solution, this HAT ensures stable, isolated two-channel CAN bus operations. It is specifically designed with multi-onboard protection circuits to safeguard your system from electrical disturbances.
This HAT integrates crucial features such as power isolation and a digital isolator for enhanced signal integrity and improved anti-interference capabilities, making communication safer and more stable. The inclusion of an SM24CANB TVS diode provides essential ESD protection and transient peak voltage protection, crucial for reliable performance in demanding environments.
Beyond Raspberry Pi compatibility, the HAT breaks out SPI control pins, allowing for flexible integration with other host control boards like STM32 or Arduino. With its robust design and protective features, this expansion HAT is well-suited for high-reliability applications such as automotive diagnostic systems, industrial automation, and other embedded control projects requiring stable CAN bus communication.
Additional Information
| Weight | 0.049 kg |
|---|---|
| Dimensions | 6.5 × 5.65 cm |
