SinoSeen OV2735 USB2.0 Wide-Angle 1080p 30fps Fixed Focus Surveillance Camera Module
The SinoSeen OV2735 is a compact USB2.0 camera module featuring a 1/2.8-inch CMOS sensor for Full HD 1080p video at 30fps, ideal for surveillance, industrial inspection, and embedded vision projects on Windows, Linux, Mac, and Android platforms.
Features
- Full HD 1080p Resolution: Delivers crisp 1920×1080 video at 30fps via a 1/2.8-inch OV2735 CMOS sensor for detailed imaging.
- Ultra-Wide 170° Field of View: Provides expansive coverage with a 2.3mm fixed-focus lens, perfect for monitoring and inspection applications.
- Plug-and-Play USB2.0 Interface: Features a high-speed 480 MB/s UVC-compliant connection for seamless integration with PCs and single-board computers.
- Enhanced Low-Light Performance: Supports IR LED assistance (940nm) for improved visibility in dark or low-light environments.
- Cross-Platform Compatibility: Works out-of-the-box with major operating systems including Windows, Linux, macOS, and Android.
Out of stock
This surveillance-grade camera module centers on the OV2735 CMOS sensor, engineered for reliable, high-frame-rate imaging in embedded systems. Its wide-angle optics capture a 170-degree diagonal field of view, minimizing blind spots for comprehensive area monitoring. The module outputs video in MJPG and YUY2 formats via a standard USB 2.0 interface, ensuring broad software compatibility and straightforward driver-free operation on most platforms.
Built for continuous operation, the module draws power directly from the USB bus (5V ±5%), simplifying system integration. The fixed-focus F/1.8 lens is optimized for objects from 60cm to infinity, while progressive scan technology ensures smooth, artifact-free video suitable for real-time processing, machine vision, and remote monitoring applications.
Additional Information
| Weight | 0.009 kg |
|---|---|
| Dimensions | 3.8 × 3.8 cm |
