Sharp Microelectronics GP1S195HCPSF Photointerrupter - Reflective Type

Name: Sharp Microelectronics GP1S195HCPSF Photointerrupter - Reflective Type
Brand: Sharp Microelectronics
SKU: SENS-1682
Price: 59.00 INR
Availability: OutOfStock

₹59.00 (Inclusive of all taxes)

Out of Stock

The Sharp Microelectronics GP1S195HCPSF is a compact, low-profile reflective photointerrupter module with phototransistor output, designed for precise non-contact object detection in space-constrained electronic systems, robotics, and industrial automation.

Features

Reflective photointerrupter with integrated phototransistor output for object detection.
Ultra-compact package dimensions of 3.4mm x 2.0mm x 2.7mm for high-density PCB mounting.
Features a narrow 1.5mm detection gap and a 0.3mm detector slit for precise sensing.
Wide operating temperature range from -25°C to +85°C for robust environmental performance.
RoHS compliant construction supporting environmentally responsible electronic designs.

Out of stock

Get Notified When Available

Description

The Sharp Microelectronics GP1S195HCPSF is a transmissive photointerrupter module engineered for reliable, non-contact detection in miniaturized applications. Its design incorporates an infrared emitter and a phototransistor detector arranged face-to-face within a single, molded housing. This configuration creates an internal light path that is interrupted by an object passing through the 1.5mm gap, providing a clean digital output signal.

Manufactured using advanced transfer and injection molding technologies, the module ensures consistent optical alignment and long-term reliability. The precise 0.3mm slit on the detector side enhances signal integrity by reducing ambient light interference. Its low-profile form factor and wide operating temperature range make it suitable for integration into consumer electronics, printer mechanisms, robotic encoders, and automated industrial equipment where space and environmental durability are critical.

Key Features

Reflective Optical Design: Integrated emitter and phototransistor detector in a single, aligned package for reliable object interruption sensing.
Miniaturized Footprint: Ultra-small 3.4mm x 2.0mm x 2.7mm package enables installation in highly space-constrained designs.
Precision Sensing Gap: 1.5mm gap width and 0.3mm detector slit provide accurate detection of small objects or edges.
Robust Environmental Rating: Operational from -25°C to +85°C, with storage capability from -40°C to +100°C.
Phototransistor Output: Provides a simple, analog-compatible output signal for easy interface with microcontrollers or logic circuits.
High-Reliability Molding: Utilizes transfer and injection molding for superior component alignment and long-term performance stability.
RoHS Compliance: Manufactured with environmentally friendly materials, meeting global restriction standards.

Applications

Paper jam and media detection in printers, copiers, and scanners.
Position sensing and limit switching in miniaturized robotics and drone mechanisms.
Rotary encoder disk interruption for motor speed and position feedback.
Object presence detection in vending machines, automated dispensers, and consumer electronics.
Slot detection and edge sensing in industrial automation and assembly line equipment.

Technical Specifications

Manufacturer Part Number	GP1S195HCPSF
Device Type	Reflective Photointerrupter
Output Type	Phototransistor
Detection Gap Width	1.5 mm
Detector Slit Width	0.3 mm
Package Dimensions (L x W x H)	3.4 mm x 2.0 mm x 2.7 mm
Operating Temperature Range	-25°C to +85°C
Storage Temperature Range	-40°C to +100°C
Compliance	RoHS

Frequently Asked Questions

What is the output type of the GP1S195HCPSF photointerrupter?

The GP1S195HCPSF provides a phototransistor output. When the internal infrared light path is uninterrupted, the phototransistor is biased on, typically pulling the output low. When an object enters the 1.5mm gap, the light path is blocked, turning the phototransistor off and causing the output state to change. This provides a simple digital signal compatible with microcontroller GPIO pins or logic-level inputs.

What are the key dimensions and mounting considerations for this sensor?

The module has an extremely compact footprint of 3.4mm (L) x 2.0mm (W) x 2.7mm (H). It is designed for surface-mount (SMD) soldering onto a PCB. The critical design parameter is the 1.5mm sensing gap; the object to be detected must pass through this air gap between the emitter and detector windows. Ensure no solder flux or contaminants obscure the optical ports during assembly.

What is the operating temperature range and what applications is it suited for?

This photointerrupter operates from -25°C to +85°C, making it suitable for a wide range of commercial and industrial environments. Its small size, reliability, and precise detection make it ideal for embedded applications such as detecting paper jams in office equipment, sensing rotational position in miniature motors or encoders, and providing limit switches in compact robotic joints and automated mechanisms.
