Plantower PMS5003 PM2.5 Laser Particle Concentration Sensor, UART, 0~500 µg/m³, 5 V, Range: 0.3~10 µm
The Plantower PMS5003 is a digital laser Particle concentration sensor with a UART interface, designed for real-time measurement of airborne particulate matter (PM1.0, PM2.5, PM10) from 0.3 to 10 µm. Operating at 5V DC, it provides direct digital output for seamless integration with microcontrollers like Arduino, Raspberry Pi, and industrial monitoring systems.
Features
- Laser scattering principle for precise Particle concentration measurement (0.3–10 µm).
- Digital UART serial interface for direct, calibrated data output.
- Wide measurement range up to ≥1000 µg/m³ with high sensitivity.
- Patented six-sided shielding ensures high anti-interference performance.
- Compact, fan-less design with flexible airflow inlet/outlet configuration.
Out of stock
The Plantower PMS5003 sensor utilizes a laser scattering detection method to count and size airborne particles in real-time. It outputs digital concentration data for PM1.0, PM2.5, and PM10 via a standard UART serial interface, eliminating the need for external analog signal conditioning. The sensor’s internal algorithm ensures a zero false alarm rate, providing reliable data for environmental monitoring.
Engineered with a patented six-sided shielding structure, the PMS5003 minimizes electromagnetic interference, ensuring stable operation in electrically noisy environments. Its compact, fan-less design allows for flexible integration into air quality monitors, HVAC systems, and portable environmental sensing devices, operating from a 4.5V to 5.5V DC power supply.
Additional Information
| Weight | 0.045 kg |
|---|---|
| Dimensions | 15 × 10 × 2 cm |
