Omron E3Z-D61 Photoelectric Sensor, NPN Open-Collector, 12-24 VDC, 5-100 mm Sensing, IP67
The Omron E3Z-D61 is a compact, self-contained photoelectric sensor with a built-in amplifier, designed for industrial automation. Operating on 12-24 VDC with an NPN open-collector output, it provides reliable detection from 5 mm to 100 mm using an 860 nm infrared LED, making it compatible with PLCs and microcontroller systems like Arduino and Raspberry Pi via interface modules.
Features
- Extended 5 mm to 100 mm sensing range with 860 nm infrared LED source
- Built-in amplifier for compact, direct integration into control systems
- Fast 1 ms response time for high-speed automation applications
- Robust IP67-rated housing for operation in harsh, dusty, or wet environments
- Wide operating temperature range from -40°C to +55°C for cold storage and industrial use
Out of stock
The Omron E3Z-D61 utilizes a modulated infrared beam and advanced photoelectric sensing principle to provide stable, long-distance detection immune to ambient light interference. Its integrated signal conditioning circuitry ensures a clean, digital NPN open-collector output signal compatible with a wide range of industrial controllers.
Engineered for demanding environments, the sensor features a tight ±2.5° optical-mechanical axis offset for simplified and highly accurate alignment during installation. The housing is sealed to IP67 standards, protecting against dust ingress and temporary immersion, while the integrated reverse polarity protection safeguards the electronics from wiring errors.
Additional Information
| Weight | 0.043 kg |
|---|---|
| Dimensions | 3.2 × 2.1 × 1.2 cm |
