Generic Mercury Medallion Sensor Module for Uno R3 - Tilt Detection Module
The Mercury Medallion Sensor Module is a basic tilt detection module designed for Arduino Uno R3 and other 3.3V/5V microcontroller platforms. It utilizes a mercury switch to detect orientation changes, providing a simple digital output signal.
Features
- Mercury switch-based tilt detection for simple orientation sensing.
- Compatible with 3.3V and 5V logic systems like Arduino Uno R3.
- Integrated indicator LED provides visual confirmation of tilt state.
- Compact PCB design with standard 2.54mm pin spacing for easy prototyping.
- Includes a 680Ω current-limiting resistor for LED and switch protection.
Out of stock
This module provides a fundamental method for detecting tilt or orientation changes through a sealed mercury switch. When the module is tilted beyond a specific angle, the conductive mercury ball moves to close or open the electrical circuit, creating a change in the output signal. The integrated LED provides immediate visual feedback, while the onboard resistor ensures safe operation within the specified voltage range.
Designed for straightforward integration, the module outputs a simple digital high/low signal compatible with digital input pins on microcontrollers like the Arduino Uno R3, ESP32, or STM32. Its operation is binary, making it suitable for applications requiring a basic tilt/no-tilt state detection without complex angle measurement.
Additional Information
| Weight | 0.002 kg |
|---|---|
| Dimensions | 2.2 × 2.4 cm |
