FrSky R9 STAB OTA Receiver
The FrSky R9 STAB OTA is a 900MHz/868MHz long-range telemetry receiver with integrated 3-axis gyroscope and accelerometer, supporting the ACCESS protocol, OTA firmware updates, and stabilization for fixed-wing and V-tail models.
Features
- ACCESS protocol receiver with Over-The-Air (OTA) firmware update capability.
- Integrated 3-axis gyroscope (±2000dps) and 3-axis accelerometer (±4g) for flight stabilization.
- Supports 8 PWM output channels (16CH telemetry) with S.Port for sensor data.
- Wide operating voltage range from 3.5V to 10V, compatible with R9M Lite/R9M/R9M 2019 modules.
- Detachable IPEX antenna for flexible installation and optimized RF performance.
Out of stock
The FrSky R9 STAB OTA receiver is engineered for long-range FPV and fixed-wing applications, operating on the robust 900MHz/868MHz band. It implements the modern ACCESS protocol, enabling seamless binding, telemetry, and convenient wireless firmware updates directly from a compatible transmitter. The built-in stabilization system, featuring a 3-axis gyro and 3-axis accelerometer, provides automatic leveling and multiple flight modes for enhanced flight control and smoother footage.
Designed for reliability, the receiver supports a wide input voltage and features a detachable antenna for optimal signal reception in diverse mounting scenarios. Its compact form factor and low current draw make it suitable for integration into a variety of aerial platforms, from long-range drones to stabilized fixed-wing aircraft.
Additional Information
| Weight | 0.0186 kg |
|---|---|
| Dimensions | 4.57 × 2.63 × 1.62 cm |
