DYP-A01BNYTB-V2.0 Ultrasonic Sensor Module - UART Controlled, 28-750cm Range
The DYP-A01BNYTB-V2.0 is a UART-controlled ultrasonic distance sensor module offering a 28–750cm measurement range with high accuracy. It is designed for easy integration with microcontrollers like Arduino, Raspberry Pi, and ESP32, as well as industrial PLCs via its configurable output interfaces.
Features
- High-precision ultrasonic ranging with ±(1 cm + 5 * 0.3%) accuracy for flat objects.
- Configurable output modes: UART (Auto/Controlled), PWM (Auto/Controlled), RS485, and Switch Output.
- Ultra-low power consumption with a static current of ≤10µA for battery-sensitive applications.
- Integrated temperature compensation ensures stable readings across varying environmental conditions.
- Wide operating voltage compatibility: 3.3–5.0V for A01A/B series, 5.0–12V for A01C series.
Out of stock
The DYP-A01BNYTB-V2.0 ultrasonic sensor employs advanced time-of-flight (ToF) measurement principles to deliver reliable distance data. Its integrated signal conditioning and temperature compensation circuitry minimize errors caused by ambient temperature fluctuations, ensuring consistent performance from -20°C to +70°C. The module’s anti-static design (IEC61000-4-2 compliant) and high electromagnetic interference resistance make it suitable for industrial and commercial environments.
Engineered for versatility, the sensor supports multiple communication protocols, allowing seamless integration into diverse systems. The UART-controlled mode provides direct serial data output for microcontroller-based projects, while PWM, RS485, and switch outputs enable compatibility with PLCs, robotic controllers, and simple threshold detection circuits. Its compact form factor and mounting holes facilitate straightforward installation.
Additional Information
| Weight | 0.035 kg |
|---|---|
| Dimensions | 16 × 10 × 4 cm |
