Digilent Cmod S7 Breadboardable Spartan-7 FPGA Module
The Digilent Cmod S7 is a compact, breadboardable FPGA module featuring a Xilinx Spartan-7 (XC7S25) device, designed for easy integration into circuit design, prototyping, and learning projects. Its 48-pin DIP form factor makes it ideal for use with solderless breadboards, offering flexible and affordable FPGA development.
Features
- Integrates a Xilinx Spartan-7 XC7S25 FPGA with 3,650 slices and 1,620 Kbits of block RAM.
- Breadboardable 48-pin DIP form factor with 32 FPGA I/O and 2 analog inputs.
- Features onboard 4MB Quad-SPI Flash for non-volatile program storage.
- Equipped with USB-JTAG programming circuitry and a USB-UART bridge.
- Includes a Pmod connector, two pushbuttons, and five user-configurable LEDs.
Out of stock
The Digilent Cmod S7 is a highly versatile, breadboardable FPGA module specifically engineered for rapid circuit design, prototyping, and educational applications. Its compact 48-pin DIP form factor allows for seamless integration into standard solderless breadboards, bringing the power of FPGA technology to a wide range of projects without complex setup. Built around a robust Xilinx Spartan-7 (XC7S25-1CSGA225C) FPGA, this module offers significant processing capabilities in a remarkably small footprint.
Key features of the Cmod S7 include a 4MB Quad-SPI flash for program storage and a comprehensive USB interface that provides both JTAG programming and a UART bridge, simplifying debugging and data communication. The board also incorporates essential onboard peripherals such as a clock source, a Pmod port for expansion, pushbuttons, and user-configurable LEDs. With 32 dedicated FPGA I/O signals and 2 analog inputs routed to 100-mil-spaced through-hole pins, the Cmod S7 offers extensive connectivity for custom circuits.
Leveraging the Spartan-7 FPGA, the Cmod S7 supports the Xilinx MicroBlaze Soft Processor Core, enabling the creation of sophisticated embedded applications with diverse peripherals, memory configurations, and interfaces. This makes it an excellent choice for developers and students looking to explore digital logic, custom embedded systems, and FPGA-based designs with a flexible and cost-effective platform.
Additional Information
| Weight | 0.017 kg |
|---|---|
| Dimensions | 8 × 3 × 3 cm |
