BMP180 Digital Barometric Pressure Sensor Module - I2C Interface
The BMP180 Digital Barometric Pressure Sensor Module is a high-precision, low-power sensor for measuring atmospheric pressure, temperature, and derived altitude. It features an I2C interface for easy integration with microcontrollers like Arduino, Raspberry Pi, ESP32, and STM32, and includes an onboard 3.3V regulator for 5V system compatibility.
Features
- High-precision piezoresistive sensor with pressure range from 300 to 1100 hPa.
- Integrated I2C digital interface (up to 3.4 MHz) for simple microcontroller connection.
- Onboard 3.3V LDO regulator enables safe operation with 5V logic systems.
- Ultra-low power consumption, with a standby current of just 0.1 µA.
- Measures barometric pressure, ambient temperature, and calculates altitude.
Out of stock
The BMP180 sensor module is built around Bosch Sensortec’s BMP180 MEMS pressure sensor, an improved successor to the BMP085. It employs advanced piezo-resistive technology to deliver high accuracy, excellent linearity, and long-term stability for barometric pressure and temperature measurements. The module’s integrated signal conditioning and digital output simplify system design.
Designed for robust performance across a wide operating temperature range from -40°C to +80°C, it is suitable for both indoor and outdoor applications. The module includes all necessary support components, such as decoupling capacitors and a pull-up resistor network for the I2C bus, providing a ready-to-use solution for embedded systems and data acquisition projects.
Additional Information
| Weight | 0.003 kg |
|---|---|
| Dimensions | 2.5 × 2 cm |
