NXP Semiconductors MPXV5100DP Differential Pressure Sensor, 0-100 kPa, Analog Voltage Output, SOP-8 Package
The NXP Semiconductors MPXV5100DP is a calibrated, temperature-compensated differential pressure sensor in an SOP-8 surface-mount package. It provides a high-level analog voltage output (0.2-4.7V) proportional to pressure, making it directly compatible with microcontroller ADC inputs for industrial automation, medical devices, and HVAC airflow monitoring.
Features
- Differential pressure sensing from 0 to 100 kPa with ±2.5% full-scale accuracy.
- Integrated on-chip signal conditioning and temperature compensation for stable analog output.
- Monolithic silicon piezoresistive MEMS design in a durable epoxy unibody package.
- Dual radial barbed ports on the same side for easy differential pressure line connection.
- Wide operating temperature range from -40°C to +125°C for harsh environments.
Out of stock
The MPXV5100DP utilizes a piezoresistive silicon MEMS sensing element integrated with signal conditioning circuitry on a single monolithic chip. This design provides a calibrated, temperature-compensated analog voltage output, significantly reducing the need for external components and simplifying system integration. The sensor’s epoxy unibody construction offers robust mechanical protection and long-term stability.
Featuring dual barbed ports for differential pressure measurement, it is ideal for monitoring pressure drops across filters, airflow in ducts, or fluid levels in non-corrosive media. The high-level output signal (45 mV/kPa sensitivity) is designed for direct interface with 5V logic microcontrollers like Arduino, Raspberry Pi, and industrial PLCs, requiring minimal additional amplification.
Additional Information
| Weight | 0.003 kg |
|---|---|
| Dimensions | 3 × 2 × 2 cm |
