Arducam 12.3MP 1/2.3-Inch HQ Camera Module w/ 6mm CS Lens for Raspberry Pi
The Arducam 12.3MP HQ Camera Module is a high-resolution, industrial-grade imaging sensor with a 6mm CS lens, designed for direct integration with Raspberry Pi 4B, 3B+, Zero, and other models via the USB Camera Shield for rapid prototyping and computer vision applications.
Features
- 12.3MP High-Resolution Sensor: Delivers detailed 4056 x 3040 pixel still images with a 1.55µm pixel size for superior clarity in industrial inspection and machine vision.
- Versatile Video Output: Supports multiple video modes including 2028x1080p50, 2028x1520p40, and 1332x990p120 for flexible streaming and recording applications.
- Broad Raspberry Pi Compatibility: Works seamlessly with Pi 4B, 3B+, 2B, 3A+, Pi Zero, and more via the included USB Camera Shield interface.
- Integrated Visible-Light Filter: Features a fixed IR-cut filter for accurate color reproduction and visible-light-only imaging.
- 65° Horizontal Field of View: The 6mm CS lens provides a balanced field of view suitable for monitoring, scanning, and detailed inspection tasks.
Out of stock
The Arducam 12.3MP HQ Camera Module is engineered for developers and system integrators requiring reliable, high-quality imaging on the Raspberry Pi platform. Its 1/2.3-inch sensor captures crisp 12.3-megapixel stills and smooth high-frame-rate video, making it ideal for applications demanding precision and detail.
Integration is streamlined through the companion USB Camera Shield, which provides a plug-and-play interface to Windows, Linux, and Raspberry Pi OS, eliminating complex driver configurations. The module’s monochrome sensor variant is particularly suited for industrial machine vision, where contrast and detail are paramount, while the integrated IR-cut filter ensures true-to-life color capture in standard visible light environments.
Additional Information
| Weight | 0.025 kg |
|---|---|
| Dimensions | 5 × 5 × 5 cm |
