Arducam B0224 OV9281 1MP Global Shutter NoIR Mono Camera w/ M12 Mount
The Arducam B0224 is a 1MP OV9281 global shutter monochrome camera module with a 130° M12 lens mount, designed for high-speed machine vision on Raspberry Pi 5/4/3/Zero and Compute Module 3+. It features a 2-lane MIPI CSI interface for plug-and-play integration with native V4L2 drivers.
Features
- 1MP OV9281 Global Shutter Sensor for crisp, undistorted capture of fast-moving objects.
- NoIR (Infrared Sensitive) design enhances low-light and IR performance for 24/7 vision applications.
- High-Speed Imaging up to 309fps at 640×400 resolution in RAW8 mode for gesture detection and tracking.
- 130° Ultra-Wide FOV M12 Lens provides a broad perspective for robotics, security, and automation.
- Native Raspberry Pi Support via 2-lane MIPI CSI interface with official drivers for easy plug-and-play setup.
Out of stock
The Arducam B0224 OV9281 camera module delivers high-performance monochrome imaging tailored for embedded machine vision and automation on the Raspberry Pi platform. Its global shutter sensor eliminates motion blur by capturing all pixels simultaneously, making it ideal for applications involving fast-moving objects, such as robotic guidance, barcode scanning, and gesture recognition.
Featuring a NoIR (No Infrared filter) sensor, the module exhibits enhanced sensitivity in low-light conditions and can be paired with IR illumination for covert surveillance or night vision. The wide 130-degree field of view M12 lens mount allows for flexible lens swapping to suit different focal lengths and application needs. With its 2-lane MIPI CSI interface, the camera connects directly to Raspberry Pi’s camera port, supported by standard V4L2 drivers for seamless integration into Python, OpenCV, or C++ based vision pipelines.
Additional Information
| Weight | 0.02 kg |
|---|---|
| Dimensions | 4 × 4 cm |
