Arducam B0597 12.3MP IMX577 Mini Camera Module for DepthAI
The Arducam B0597 is a 12.3MP Sony IMX577-based camera module designed for DepthAI OAK systems, featuring a compact M12 lens mount and MIPI CSI-2 interface for high-resolution computer vision and edge AI applications on embedded platforms.
Features
- 12.3MP Sony IMX577 sensor delivers high-resolution imagery for precise object detection and advanced computer vision tasks.
- Optimized for DepthAI (DM1090FFC/OAK) platforms, ensuring seamless integration for robotics and AI projects.
- Compact mini form factor (25x24mm) and lightweight design ideal for drones, robots, and space-constrained embedded systems.
- Low-distortion wide-angle lens with an 88° diagonal FOV captures expansive scenes with minimal edge distortion.
- Flexible MIPI CSI-2 interface supports both 2-lane (default) and 4-lane configurations for adaptable data bandwidth.
Out of stock
The Arducam B0597 Mini Camera Module integrates the high-performance Sony IMX577 CMOS sensor into a compact, vision-optimized package for DepthAI-powered edge computing. Its 1/2.3-inch optical format and 1.55µm pixel size provide excellent light sensitivity and detail capture, supporting frame rates up to 30 fps at 1080p for dynamic scene analysis.
Engineered for seamless integration with the DepthAI ecosystem, this module outputs RAW image data via a configurable MIPI CSI-2 interface, allowing developers to balance bandwidth and power consumption. The fixed-focus M12 lens assembly features an integrated 650nm IR filter and an 80cm to infinity focus range, making it suitable for both indoor and outdoor AI vision applications requiring stable, high-fidelity input.
Additional Information
| Weight | 0.01 kg |
|---|---|
| Dimensions | 2.5 × 2.4 cm |
