YDLIDAR SDM15 Outdoor 15M Single Point Ranging Laser Sensor Module with USB Adapter Board
The YDLIDAR SDM15 is a high-precision, single-point laser ranging module based on Time-of-Flight (TOF) principle, offering a 15-meter range and 1.8kHz sampling rate. It features a compact, lightweight design with a USB Type-C interface, making it compatible with ROS, ROS2, STM32, and Linux-based systems for robotics and UAV applications.
Features
- High-precision TOF laser ranging up to 15 meters with a fast 1.8kHz sampling frequency.
- Compact and lightweight design (17.2 x 45 x 22.3 mm) for integration into drones, robots, and mobile platforms.
- Robust performance in high-ambient-light conditions, capable of resisting up to 60,000 Lux.
- Direct USB Type-C interface via included adapter board for easy connection to PCs and embedded hosts.
- Supported by ROS, ROS2, STM32, and Linux tutorials for rapid development in navigation and obstacle avoidance.
Out of stock
The YDLIDAR SDM15 is engineered for precise, single-point distance measurement using a Time-of-Flight (TOF) laser. It delivers stable, low-error readings at a high sampling rate, suitable for dynamic environments. Its compact form factor and high ambient light immunity make it ideal for both indoor and outdoor applications.
This module outputs serial data via a configurable baud rate (460800 to 1,500,000 bps), allowing seamless integration with microcontrollers like STM32 or single-board computers running Linux. The included USB adapter board simplifies power and communication, enabling quick prototyping and system integration for autonomous navigation and fixed-height obstacle detection.
Additional Information
| Weight | 0.06 kg |
|---|---|
| Dimensions | 4.5 × 1.72 × 2.23 cm |
