Waveshare XNUCLEO-F103RB STM32 NUCLEO Development Board
The Waveshare XNUCLEO-F103RB is an enhanced development board featuring the STM32F103RBT6 ARM Cortex-M3 microcontroller. It provides Arduino shield compatibility and ST Morpho headers for versatile peripheral expansion, accelerating rapid prototyping with mbed SDK.
Features
- Features STM32F103RBT6 ARM Cortex-M3 microcontroller, operating at 72MHz.
- Offers comprehensive Arduino connectivity for shield integration and vast resource access.
- Includes ST Morpho headers for full access to all STM32 I/Os, facilitating easy expansion.
- Supports mbed SDK and online tools for rapid prototype development.
- Comes with a dedicated ST-LINK/V2 module for programming and debugging.
Out of stock
The Waveshare XNUCLEO-F103RB is an improved STM32 NUCLEO-compatible development board, built around the powerful STM32F103RBT6 ARM Cortex-M3 microcontroller. This board provides a robust platform for embedded system design, offering high performance at 72MHz, coupled with 128KB Flash and 20KB SRAM. Its design prioritizes developer flexibility, featuring comprehensive Arduino connectivity that allows seamless integration with a wide array of existing Arduino shields, alongside ST Morpho headers that provide full access to all STM32 I/Os for advanced peripheral expansion.
Key onboard components enhance its utility, including a CP2102 USB to UART converter for reliable debugging, SPX3819M5 and AMS1117-5.0 voltage regulators for stable power delivery, and both 8MHz and 32.768KHz crystals for precise timing. The board supports the mbed SDK, enabling rapid prototyping and leveraging online development tools. For robust programming and debugging, a dedicated ST-LINK/V2 module is included in the package, streamlining the firmware development cycle.
The XNUCLEO-F103RB boasts flexible power options, allowing operation via USB or an external 6-12V DC input, configurable through onboard jumpers. User interaction is facilitated by dedicated user and reset buttons, and an LED indicator. Furthermore, a suite of configurable jumpers for ADC/I2C selection, UART configuration, power source, and user I/Os provides granular control, making it an adaptable choice for a wide spectrum of embedded projects from IoT to industrial automation.
Additional Information
| Weight | 0.176 kg |
|---|---|
| Dimensions | 8 × 12 × 5 cm |
