Waveshare Mini Base Board (A) for Raspberry Pi CM5
The Waveshare Mini Base Board (A) is a compact carrier board designed for the Raspberry Pi Compute Module 5 (CM5), supporting both Lite and eMMC variants. It provides essential connectivity with dual HDMI, USB 3.2 Gen1, Gigabit Ethernet, and PCIe Gen2/3 x1, enabling rapid prototyping and embedded system integration.
Features
- Compact carrier board specifically for Raspberry Pi Compute Module 5 (Lite/eMMC).
- Features dual HDMI outputs, supporting resolutions up to 4K for multi-display setups.
- Integrates 2x USB 3.2 Gen1 Type-A ports and 2x USB 2.0 via FFC for versatile peripheral connectivity.
- Includes a 16PIN PCIe Gen2/3 x1 interface for high-speed expansion modules.
- Equipped with Gigabit Ethernet and a standard 40-pin GPIO header for comprehensive I/O.
Out of stock
The Waveshare Mini Base Board (A) serves as a dedicated carrier for the Raspberry Pi Compute Module 5, offering a highly compact yet comprehensive platform for various embedded applications. It efficiently breaks out the core functionalities of the CM5, providing developers with a robust foundation for integrating the powerful module into custom projects, from industrial control systems to multimedia applications.
Designed with a small form factor, this base board is ideal for projects where space is a premium, without compromising on essential connectivity. It supports both CM5 Lite and eMMC variants, ensuring broad compatibility, and features flexible mounting options for seamless integration into diverse enclosures and setups.
Key interfaces include dual HDMI ports for multi-display setups, multiple USB 3.2 Gen1 and USB 2.0 ports for peripherals, and a Gigabit Ethernet connector for reliable networking. Additionally, a 16-pin PCIe Gen2/3 x1 interface allows for high-bandwidth expansion, making it suitable for advanced data processing and I/O tasks.
Additional Information
| Weight | 0.05 kg |
|---|---|
| Dimensions | 8.5 × 5.6 cm |
