Sharp Microelectronics GP1S58VJ000F Photointerrupter - Reflective Type
The Sharp Microelectronics GP1S58VJ000F is a compact reflective-type photointerrupter integrating an infrared emitter and phototransistor detector in a single through-hole package, designed for precise non-contact object detection in PCB-mounted applications.
Features
- Reflective-type photointerrupter with integrated IR emitter and phototransistor detector.
- Compact through-hole package (13.7 x 10 x 5.2 mm) with built-in positioning pins for accurate PCB alignment.
- Features a 5 mm sensing gap and a 0.5 mm vertical slit for precise object detection.
- Wide operating temperature range from -25°C to +85°C for robust environmental performance.
- Ideal for position sensing, edge detection, and speed measurement in consumer electronics and automation.
Out of stock
The GP1S58VJ000F from Sharp Microelectronics is a reflective-type photointerrupter module that combines an infrared LED emitter and a silicon phototransistor within a single, compact housing. This configuration creates an integrated optical gate where the emitted IR light reflects off a target object back to the detector, enabling non-contact sensing without the need for a separate receiver unit. The device is housed in a case-style through-hole package, simplifying PCB integration for volume manufacturing.
Engineered for reliability, the module includes molded positioning pins to prevent misalignment during assembly, ensuring consistent optical performance. The defined 5 mm sensing gap and 0.5 mm detector slit width allow for precise detection of small objects or fine positional changes. With an operating temperature range of -25°C to +85°C, this sensor is suitable for integration into a wide array of electronic and electromechanical systems requiring durable, maintenance-free operation.
Additional Information
| Weight | 0.0005 kg |
|---|---|
| Dimensions | 1.37 × 1 × 0.52 cm |
