Seeed Studio Studio Grove EC Sensor Kit (DJS1CBlack) - BNC Probe Interface, 0-2000 µS/cm Range
The Seeed Studio Studio Grove EC Sensor Kit is a compact electrical conductivity measurement module designed for 3.3V/5V systems, featuring a BNC probe interface for easy integration with Arduino and Raspberry Pi platforms for water quality monitoring and aquaculture applications.
Features
- Measures electrical conductivity (EC) from 0 to 2000 µS/cm with ±5% resolution (STP).
- Operates on 3.3V or 5V DC, compatible with Arduino, Raspberry Pi, and other microcontroller platforms.
- Features a standard BNC connector for the included probe and a Grove interface for simplified wiring.
- Fast response time of less than 10 seconds for dynamic water quality monitoring.
- Wide operating temperature range from 5°C to 80°C for robust environmental performance.
Out of stock
The Grove EC Sensor functions by measuring the electrical conductivity of a solution, which correlates directly with the concentration of dissolved ionic solids. This sensor employs a driver board that conditions the signal from a two-electrode probe, providing a stable analog output suitable for precise ADC measurement. The system is engineered for reliability in continuous monitoring scenarios, with a durable probe designed for aqueous environments.
Integration is streamlined via the Grove connector system, which handles power and signal lines, reducing wiring complexity. The driver board’s compatibility with both 3.3V and 5V logic levels ensures seamless operation with a wide range of development boards and industrial data acquisition systems, making it a versatile tool for water quality analysis and process control.
Additional Information
| Weight | 0.1 kg |
|---|---|
| Dimensions | 10 × 23 × 1 cm |
