RP2040-Zero Microcontroller without Soldering
The RP2040-Zero is a compact, high-performance microcontroller board featuring the Raspberry Pi RP2040 chip with a dual-core ARM Cortex M0+ processor, 264KB SRAM, and 2MB Flash memory. Designed for embedded projects and IoT, this board offers extensive GPIOs and USB-C connectivity, ready for immediate use without soldering.
Features
- Features the powerful dual-core ARM Cortex M0+ RP2040 microcontroller.
- Integrates 264KB SRAM and 2MB of onboard Flash storage for programs and data.
- Provides 29 multi-function GPIO pins, supporting SPI, I2C, and UART interfaces.
- Equipped with a USB-C port for power, data, and drag-and-drop programming.
- Comes pre-soldered, enabling immediate prototyping without additional assembly.
Out of stock
The RP2040-Zero is a versatile, low-cost, and high-performance microcontroller board built around Raspberry Pi’s custom RP2040 silicon. Its compact footprint makes it ideal for space-constrained projects, while its design ensures broad compatibility with the existing Raspberry Pi Pico ecosystem.
At its core, the board features a dual-core ARM Cortex M0+ processor running at up to 133 MHz, coupled with 264KB of SRAM and 2MB of dedicated Flash memory. This configuration provides ample processing power and storage for a wide range of embedded applications, from simple sensor reading to more complex IoT tasks. Connectivity options are robust, including 29 multi-function GPIO pins, two SPI, two I2C, and two UART interfaces.
Furthermore, the RP2040-Zero incorporates USB 1.1 device and host support via its convenient USB-C connector, facilitating easy programming through drag-and-drop mass storage. Its eight Programmable I/O (PIO) state machines enable custom high-speed peripheral support, expanding its utility for specialized hardware interactions. With built-in low-power modes and an on-chip temperature sensor, it is well-suited for energy-efficient, battery-powered deployments.
Additional Information
| Weight | 0.03 kg |
|---|---|
| Dimensions | 6 × 5 × 2 cm |
