Pro-Range E50S8G5-2500Z-G24F Rotary Incremental Encoder - 50mm, Photoelectric, ABZ 3 Channels, 2500 PPR
The Pro-Range E50S8G5-2500Z-G24F is a high-precision 50mm rotary incremental encoder delivering 2500 pulses per revolution (PPR) via ABZ three-channel photoelectric output. Operating from 5-24V DC, it provides reliable position and speed feedback for integration with industrial PLCs, servo drives, and motion control systems.
Features
- High-resolution 2500 PPR (Pulses Per Revolution) for precise angular position and speed measurement.
- ABZ three-channel incremental output (A, B, Z index) for enhanced signal reliability and direction detection.
- Wide operating voltage range of 5-24V DC for flexible compatibility with industrial controllers and embedded systems.
- Compact 50mm diameter photoelectric design with robust construction for demanding industrial and robotic environments.
- Standard mounting with a 50mm PCB hole pattern for straightforward mechanical integration.
Out of stock
The Pro-Range E50S8G5-2500Z-G24F encoder utilizes a photoelectric sensing principle, where a light source and photodetector read a patterned disk to generate precise digital quadrature pulses. This method ensures high accuracy and long-term reliability with minimal mechanical wear.
Designed for industrial motion control, the encoder outputs standard ABZ signals, where channels A and B are 90° out of phase for direction sensing, and the Z channel provides a single index pulse per revolution for absolute reference. Its wide 5-24V DC input range allows direct connection to common PLC digital inputs, servo drive feedback ports, and microcontroller interfaces with appropriate level shifting.
Additional Information
| Weight | 0.214 kg |
|---|---|
| Dimensions | 9 × 9 × 7 cm |
