Pro-Range E38S6G5-100Z-G24N Rotary Incremental Encoder - 38mm, Photoelectric, ABZ 3 Channels, 100 PPR
The Pro-Range E38S6G5-100Z-G24N is a compact 38mm diameter rotary incremental encoder delivering 100 pulses per revolution (PPR) via photoelectric sensing. Featuring ABZ 3-channel quadrature output, it provides precise position and direction feedback for integration with PLCs, motor drives, and industrial automation systems operating on a 5-24V DC supply.
Features
- 100 PPR Photoelectric Encoder: Delivers precise incremental position feedback with a resolution of 100 pulses per revolution.
- Compact 38mm Diameter: Space-saving design ideal for integration into motors and machinery with limited mounting area.
- ABZ 3-Channel Quadrature Output: Provides A and B phase signals for direction detection and a Z-index (zero) pulse for homing and reference positioning.
- Wide Voltage Range: Operates from 5V to 24V DC, compatible with common industrial logic levels and power supplies.
- Industrial Durability: Robust construction designed for reliable performance in demanding automation and motion control environments.
Out of stock
The Pro-Range E38S6G5-100Z-G24N incremental encoder utilizes a photoelectric sensing mechanism, where an infrared LED and phototransistor detect interruptions in a coded disk to generate precise digital pulses. This method ensures high signal integrity and resistance to electrical noise compared to magnetic or contact-based designs.
Its ABZ output provides standard quadrature encoding (A and B channels 90 degrees out of phase) for determining rotational direction and speed, while the Z channel outputs a single pulse per revolution for absolute reference. The encoder is built for industrial applications, with a rated speed of up to 6000 RPM and a durable housing suitable for factory automation, CNC machinery, and servo motor feedback systems.
Additional Information
| Weight | 0.142 kg |
|---|---|
| Dimensions | 8.5 × 8.5 × 6.5 cm |
