onsemi AR0237CSSC12SPRA0-DR 3µm CMOS Image Sensor 1920x1080 PLCC-48

Name: onsemi AR0237CSSC12SPRA0-DR 3µm CMOS Image Sensor 1920x1080 PLCC-48
Brand: onsemi
SKU: SENS-1725
Price: 1619.00 INR
Availability: OutOfStock

₹1,619.00 (Inclusive of all taxes)

Out of Stock

The onsemi AR0237CSSC12SPRA0-DR is a high-performance 1/2.7-inch CMOS image sensor delivering 2.1MP (1920×1080) resolution with a 3.0µm pixel design, ideal for machine vision, automotive rear-view cameras, and security systems requiring high dynamic range and low-light sensitivity.

Features

2.1MP (1920×1080) resolution with 3.0µm pixel pitch for detailed image capture.
PLCC-48 surface-mount package (11.4×11.4mm) for compact, integrated designs.
Wide operating temperature range of -30°C to +85°C for industrial and automotive use.
Low power consumption of 300mW for energy-efficient embedded applications.
Supports high dynamic range (HDR) imaging for challenging lighting conditions.

Out of stock

Get Notified When Available

Description

The AR0237CSSC12SPRA0-DR from onsemi is a rolling-shutter CMOS image sensor engineered for demanding vision applications. Its 3.0µm backside-illuminated (BSI) pixel architecture provides enhanced Quanum efficiency and low-light performance, while integrated features support advanced color reproduction and real-time monitoring capabilities.

Designed for system integration, this sensor outputs digital video data through a high-speed serial interface, compatible with common image signal processors (ISPs) and FPGAs. Its robust PLCC-48 package and extended industrial temperature rating make it suitable for deployment in automotive driver assistance systems, industrial inspection, and surveillance cameras where reliability and image quality are critical.

Key Features

High-resolution 2.1-megapixel sensor with 1080p Full HD output.
Advanced 3.0µm BSI pixel technology for superior low-light sensitivity and reduced noise.
Integrated high dynamic range (HDR) support for scenes with extreme contrast.
Compact PLCC-48 package with a footprint of 11.4 x 11.4 mm.
Wide operating temperature range from -30°C to +85°C ensures performance in harsh environments.
Low-power design with typical consumption of 300mW for portable and battery-operated devices.
RoHS compliant construction for environmentally conscious manufacturing.

Applications

Automotive rear-view cameras and surround-view monitoring systems.
Industrial machine vision for quality control and robotic guidance.
High-definition security and surveillance camera modules.
Consumer electronics requiring compact, high-performance imaging.
Drone and UAV vision systems for navigation and inspection.

Technical Specifications

Manufacturer Part Number	AR0237CSSC12SPRA0-DR
Brand	onsemi
Sensor Type	CMOS Image Sensor
Resolution	1920 (H) x 1080 (V) - 2.1 MP
Pixel Size	3.0 µm x 3.0 µm
Package Type	PLCC-48
Package Dimensions	11.4 mm x 11.4 mm
Number of Pins	48
Power Consumption	300 mW (Typical)
Operating Temperature	-30°C to +85°C
Compliance	RoHS

Frequently Asked Questions

What is the resolution and output format of the AR0237CS sensor?

The AR0237CSSC12SPRA0-DR provides a 2.1-megapixel resolution of 1920x1080 pixels (1080p Full HD). It outputs digital video data through a high-speed serial interface, typically using a parallel or MIPI CSI-2 interface, which must be confirmed in the specific application note or datasheet for your integration.

What is the operating voltage and power consumption of this image sensor?

While the exact I/O voltage levels are detailed in the datasheet, this CMOS sensor typically operates from a single low-voltage supply (e.g., 1.8V or 2.8V for core and I/O). Its typical power consumption is 300mW, making it suitable for power-sensitive embedded vision applications.

Is this sensor suitable for automotive or outdoor applications?

Yes, the AR0237CS is designed for demanding environments. Its operating temperature range of -30°C to +85°C and support for features like HDR make it well-suited for automotive ADAS cameras, rear-view systems, and outdoor security cameras that must perform reliably under varying weather and lighting conditions.

How do I interface this PLCC-48 sensor with my processor or FPGA?

Interfacing requires a compatible socket or direct soldering onto a PCB. You must design your board to supply the correct voltages, provide a stable clock source, and route the high-speed data lines according to the sensor's pinout and timing specifications outlined in the official onsemi datasheet. An accompanying image signal processor (ISP) is typically required.
