NICEMCU BW16 RTL8720DN Dual-band WiFi & BLE 5.0 Development Board w/ IPEX Antenna

First, install the Arduino IDE and add the BW16 board support via the Board Manager using the appropriate package URL. Select 'NICEMCU BW16' from the boards list. Connect the board via USB, choose the correct COM port, and upload your sketch. The board uses standard Arduino functions for GPIO, WiFi, and BLE, but you may need to include specific libraries for the RTL8720DN's dual-band WiFi features. Ensure your power supply provides a stable 5V at 500mA.

The pre-soldered IPEX connector allows you to attach an external antenna for improved wireless range or directional coverage, which is useful when the device is inside an enclosure. To use it, disconnect the PCB trace antenna by software configuration (often via AT commands or library functions) to switch the RF path to the external port. Then, screw a compatible 50-ohm IPEX-to-SMA pigtail or directly connect an IPEX antenna. Proper impedance matching is critical for optimal RF performance and minimal signal loss.

The board requires a 5V supply with a recommended current capacity of at least 500mA for stable operation, especially when the radio is transmitting. For battery-powered applications, you can use a 3.7V LiPo with a boost converter to 5V. The RTL8720DN SoC supports various low-power sleep modes. Deep sleep current can drop to microamps, but you must configure the GPIOs and peripherals correctly in your firmware. Always measure actual consumption with your specific code and RF activity, as BLE advertising or WiFi connections will periodically wake the device and increase average current.
