XBee Adapter Shield Breakout Board
XBee Adapter Shield Breakout Board - Image 2
XBee Adapter Shield Breakout Board - Image 3
XBee Adapter Shield Breakout Board - Image 4
XBee Adapter Shield Breakout Board - Image 5
SKU: SBCD-0197
📋 GST Invoice Available

XBee Adapter Shield Breakout Board

₹134.00 (Inclusive of all taxes)
Out of Stock

The XBee Adapter Shield Breakout Board provides a convenient interface for integrating XBee modules with Arduino development boards. It converts the 20-pin XBee footprint to a standard 0.1-inch dual-row header, enabling robust wireless communication solutions for your projects.

Features

  • Designed for seamless integration of XBee modules with Arduino boards.
  • Converts 20-pin XBee to standard 0.1-inch dual-row pin spacing.
  • Enables wireless communication up to 100 feet indoors and 300 feet outdoors.
  • Features clear pinout screen prints for easy identification and setup.

Out of stock

Description

This XBee Adapter Shield serves as an essential bridge for developers looking to incorporate Zigbee-based wireless capabilities into their Arduino projects. Designed to accommodate various compatible XBee modules (sold separately), it provides the flexibility to select the optimal wireless solution for specific application needs. The shield simplifies the connection process, breaking out each XBee pin to a solderable through-hole pad for straightforward interfacing.

By enabling wireless communication, this shield allows Arduino boards to interact with other XBee-enabled devices, facilitating data exchange over considerable distances. It supports indoor ranges of up to 100 feet and extends to 300 feet outdoors with a clear line-of-sight, making it suitable for a wide array of IoT, remote sensing, and control applications. Its design prioritizes ease of use, with clearly marked pins to streamline development and integration efforts.

Key Features

  • Simple adapter board design for use with XBee modules.
  • Adapts XBee 20-pin footprint to dual-row pins with 0.1-inch standard spacing.
  • Dual rows with 0.5-inch distance for broader compatibility.
  • Clearly identifies pins with corresponding screen prints for easy wiring.
  • Designed for solder-free connection to the board using a female socket.
  • Enables wireless communication for Arduino boards using Zigbee protocol.
  • Supports indoor communication range up to 100 feet.
  • Supports outdoor communication range up to 300 feet (line-of-sight).

Applications

  • Wireless sensor networks with Arduino.
  • Remote control and monitoring systems.
  • IoT device communication and data collection.
  • Home automation projects.
  • Robotics and autonomous vehicle communication.

Technical Specifications

CompatibilityXBee Modules, Arduino Boards
Indoors Communication RangeUp to 100 feet
Outdoors Communication RangeUp to 300 feet (line-of-sight)
Number of Pins20 (XBee footprint)
Pin Spacing (Breakout)0.1-inch standard, dual-row
Dual Row Distance0.5-inch

Frequently Asked Questions

What XBee modules are compatible with this adapter shield?

This adapter shield is designed for standard 20-pin XBee modules from Digi International. It accommodates various series, including XBee Series 1 (802.15.4), XBee-PRO, and XBee Series 2 (Zigbee), allowing flexibility in choosing the specific wireless protocol and range requirements for your project.

How do I power the XBee module when using this shield?

The XBee module typically draws power directly from the Arduino board via the shield's pin connections. This shield connects to the Arduino's 3.3V power supply, which is standard for most XBee modules. Ensure your Arduino can supply sufficient current for the chosen XBee model.

Can this shield be stacked with other Arduino shields?

Due to its form factor and direct connection to Arduino pins, stacking this XBee adapter shield directly with other shields might be challenging without additional headers or modifications. It's often best used as the top shield or with careful planning for pin conflicts.

What software libraries or tools are required to use XBee with Arduino?

To interface an XBee module with Arduino, you typically use the `XBee-Arduino` library, available through the Arduino IDE's Library Manager. This library simplifies sending and receiving data frames and configuring the XBee module, making it easier to implement wireless communication.

Package Includes

  • 1 x XBee Adapter Shield Breakout Board for XBee Module

Additional Information

Weight 0.02 kg
Dimensions 6 × 4 × 2 cm
