iFlight BLITZ Whoop F7 AIO V1.1 (2-6S 55A ESC)
The iFlight BLITZ Whoop F7 AIO V1.1 is a high-performance, all-in-one flight controller and 55A ESC stack designed for 2-6S LiPo builds. Featuring an STM32F745 MCU and ICM42688 gyro, it offers HD digital system pass-through for DJI O3 and CaddxFPV Vista/Polar, making it ideal for compact, high-performance FPV drones.
Features
- High-performance STM32F745 BGA MCU running at 216MHz for advanced flight firmware support (Betaflight, Emuflight).
- Integrated 55A continuous (65A burst) 2-6S BLHeli_S 4-in-1 ESC with powerful MOSFETs.
- Separated FC and ESC PCB design minimizes electrical noise for superior gyro performance.
- Direct HD digital video pass-through for DJI O3 Air Unit and CaddxFPV Vista/Polar systems.
- Onboard 16MB Blackbox flash memory and AT7456E OSD chip for data logging and telemetry.
Out of stock
The BLITZ Whoop F7 AIO V1.1 integrates a robust flight controller and a powerful 4-in-1 ESC into a single, compact unit. Its separated board architecture physically isolates the flight controller from the high-current ESC circuits, dramatically reducing electrical noise and vibration interference for the sensitive ICM42688 gyro. This results in exceptionally clean flight characteristics and precise control.
Built around a BGA-packaged STM32F745 microcontroller, the board provides ample processing headroom for current and future flight firmware development. The 55A continuous-rated ESCs utilize high-quality MOSFETs capable of handling burst currents up to 65A, supporting a wide range of motor sizes from micro whoops to larger 5-inch freestyle builds. The integrated 5V/2.5A BEC ensures stable power for peripherals like receivers and VTXs.
Additional Information
| Weight | 0.045 kg |
|---|---|
| Dimensions | 8 × 8 × 4 cm |
