HOTRC CT-6A Transmitter + F-06A Receiver (PWM) - 2.4GHz FHSS
HOTRC CT-6A Transmitter + F-06A Receiver (PWM) - 2.4GHz FHSS - Image 2
HOTRC CT-6A Transmitter + F-06A Receiver (PWM) - 2.4GHz FHSS - Image 3
HOTRC CT-6A Transmitter + F-06A Receiver (PWM) - 2.4GHz FHSS - Image 4
SKU: DRFC-3345
📋 GST Invoice Available

HOTRC CT-6A Transmitter + F-06A Receiver (PWM) - 2.4GHz FHSS

₹2,179.00 (Inclusive of all taxes)
Out of Stock

The HOTRC CT-6A Transmitter and F-06A Receiver is a 2.4GHz FHSS radio control system delivering precise PWM output for servo and motor control, compatible with a wide range of RC models and UAV platforms requiring reliable, low-latency command links.

Features

  • 2.4GHz FHSS (Frequency Hopping Spread Spectrum) technology for stable, interference-resistant communication.
  • Low-latency PWM output with a reaction speed of ≤20ms for responsive control.
  • Multi-channel transmitter with 4096-step resolution for fine-tuned, high-precision operation.
  • Wide voltage compatibility for both transmitter and receiver (DC 4V-9V).
  • Integrated Bluetooth 5.1 dual-mode function for potential app connectivity and telemetry.

Out of stock

Description

The HOTRC CT-6A and F-06A system is engineered for dependable wireless control in RC and light UAV applications. The CT-6A transmitter provides a robust, user-friendly interface with multi-channel support and high-resolution sticks, ensuring stable command transmission even in congested RF environments.

The companion F-06A receiver is built for resilience, delivering accurate Pulse Width Modulation (PWM) signals to servos, ESCs, and actuators. Its enhanced sensitivity (-96dBm) and robust FHSS protocol maintain a reliable link over operational distances, making it a solid choice for pilots and builders seeking a straightforward, performance-oriented radio link.

Key Features

  • Advanced 2.4GHz FHSS Link: Employs Frequency Hopping Spread Spectrum for superior resistance to interference and stable signal integrity.
  • High-Precision Control: Transmitter features 4096-step resolution on control channels for smooth, accurate stick inputs.
  • Fast System Response: PWM signal reaction time of ≤20ms ensures immediate, lag-free control feedback.
  • Wide Operating Voltage: Both transmitter and receiver operate on a flexible DC 4V to 9V input, compatible with various battery configurations.
  • Integrated Bluetooth 5.1: Supports dual-mode Bluetooth connectivity for potential smartphone integration, telemetry display, or model configuration.
  • Durable Construction: Designed with quality components to withstand the vibrations and demands of RC and UAV operation.

Applications

  • Command and control for lightweight FPV and line-of-sight multirotor drones.
  • Primary radio link for RC car, boat, and robot projects requiring reliable PWM output.
  • Backup or trainer transmitter setup for pilot skill development.
  • Ground control station for simple UAV payloads or camera gimbal control.

Technical Specifications

ModelCT-6A Transmitter + F-06A Receiver (PWM)
RF System2.4GHz ISM Band, FHSS (Frequency Hopping Spread Spectrum)
ModulationGFSK
RF Power~90mA
Control Resolution4096 Steps
PWM Reaction Speed≤20ms
Operating Range~300 meters
Receiver Sensitivity-96dBm
Transmitter VoltageDC 4V - 9V
Receiver VoltageDC 4V - 9V
BluetoothBluetooth 5.1 Dual Mode

Frequently Asked Questions

What is the maximum control range of the HOTRC CT-6A system?

The system is rated for an approximate operational range of 300 meters in open, line-of-sight conditions. Actual range can be affected by local RF interference, antenna orientation, and physical obstacles.

What voltage do I need to power the transmitter and receiver?

Both the CT-6A transmitter and the F-06A receiver operate on a wide DC input range of 4V to 9V. This makes them compatible with common battery sources like a 2S LiPo (7.4V nominal) or a set of AA batteries, providing flexibility for various builds.

Can I use this system with standard servos and ESCs?

Yes. The F-06A receiver outputs standard PWM signals, making it directly compatible with most hobby-grade servos, brushed ESCs, and basic brushless ESCs that accept a PWM input. It is ideal for controlling actuators in RC models and simpler drone setups.

What is the benefit of the integrated Bluetooth 5.1?

The Bluetooth 5.1 dual-mode function allows the transmitter to potentially connect to smartphone apps for telemetry display, model configuration, or firmware updates. It adds a layer of connectivity for enhanced setup and monitoring without needing a physical USB connection.

Package Includes

  • 1 x HOTRC CT-6A Transmitter
  • 1 x HOTRC F-06A Receiver (PWM)

Additional Information

Weight 0.456 kg
Dimensions 19 × 25 × 10 cm
