HappyModel SE0702 KV26000 Brushless Motor (CW)
The HappyModel SE0702 is an ultra-lightweight 0702 brushless motor rated for 26000KV, engineered for 1S LiPo power systems in micro and nano drone builds. Its compact 9.5mm x 14mm form factor and 1mm shaft diameter are optimized for high-RPM performance in tiny whoop and racing drone applications.
Features
- Ultra-lightweight 1.5g construction for maximum power-to-weight ratio in micro builds.
- High 26000KV rating delivers exceptional RPM for rapid throttle response on 1S LiPo.
- Compact 7mm stator diameter and 9N12P magnetic configuration for efficient power density.
- 1mm shaft diameter compatible with 31mm and 40mm bi-blade propellers for micro FPV.
- Designed for integration into ultra-lightweight tiny whoop and nano racing drone frames.
Out of stock
The SE0702 brushless motor from HappyModel represents a specialized component for the extreme end of micro drone performance. Its 26000KV rating, paired with a 9N12P magnetic configuration, is engineered to extract maximum rotational speed from a single-cell LiPo battery, providing the intense thrust required for acrobatic tiny whoop flight and competitive nano racing.
Constructed with a focus on minimal mass, the motor’s 1.5g weight is critical for maintaining agile flight characteristics in sub-20g builds. The 7mm stator and robust internal bearings ensure reliable operation at high rotational speeds, while the 1mm shaft provides a secure mounting point for dedicated micro propellers, balancing durability with the demands of lightweight design.
Additional Information
| Weight | 0.0015 kg |
|---|---|
| Dimensions | 1.4 × 0.95 cm |
