Generic DB9 Male RS232/RS485 Terminal Adapter - Screw Terminal Block, Nut Lock

This adapter is a passive wiring breakout; it provides physical access to the connector pins. To use it for RS232 or RS485, you must connect it to an appropriate active interface circuit or transceiver chip that generates the correct voltage levels and signal conditioning for the desired standard (e.g., a MAX232 for RS232 or a MAX485 for RS485).

The nut-lock design allows the adapter to be securely fastened to a panel, enclosure, or chassis using the threaded posts on the DB9 connector. This prevents the connector from loosening due to vibration or cable strain, ensuring a reliable mechanical connection in industrial or mobile applications.

Yes, this adapter is commonly used for that purpose. You would wire the relevant pins (like TxD, RxD, and GND) from the terminal block to your microcontroller's UART pins, typically through a level-shifting circuit (like a MAX232) to convert between RS232 voltage levels (±3V to ±15V) and microcontroller logic levels (0-3.3V or 0-5V).

The 3.96mm pitch screw terminals are designed to accept standard stranded or solid core wires, typically in the range of 22 to 18 AWG. The 2mm screw hole diameter accommodates the included or standard M2 screws for securing the wire under the terminal.
