SKU: DRFC-2933
📋 GST Invoice Available

Generic A2212 1400KV Brushless Motor Set with SimonK 30A ESC and OrangeRX 1045 Propellers - 4-Pack

₹2,827.44 (Inclusive of all taxes)
Out of Stock

The Generic A2212 1400KV brushless motor set is a complete propulsion solution for DIY multirotor and fixed-wing UAVs, paired with SimonK 30A ESCs and 1045 propellers. This 4-pack combo supports 2S-3S LiPo batteries and is engineered for smooth throttle response and reliable performance in entry-level and endurance-focused drone builds.

Features

  • Complete 4-Pack Propulsion System: Includes four A2212 1400KV motors, four SimonK 30A ESCs, and four pairs of 1045 propellers.
  • Optimized for Endurance: 1400KV rating and 2S-3S LiPo compatibility deliver efficient thrust for long-range and medium-lift applications.
  • Robust Motor Construction: Features a solid metal case, 3.17mm shaft, and a 14-pole design for reliable, durable operation.
  • Integrated Power Management: Each SimonK ESC includes an On-Board BEC for clean 5V power to auxiliary electronics.
  • Bi-Directional Operation: Motors can rotate CW or CCW by swapping input polarity, simplifying frame integration and wiring.

Out of stock

Description

This A2212 1400KV brushless motor combo provides a foundational power system for custom drone and RC aircraft projects. The motors utilize a 14-pole stator design within a machined aluminum housing, balancing weight and heat dissipation for sustained operation. Their 1400KV rating is specifically tuned for efficient thrust on 2S and 3S battery packs, making them suitable for trainers, aerial photography platforms, and endurance multirotors.

The included SimonK 30A Electronic Speed Controllers feature robust firmware for precise, low-latency throttle control and incorporate a switching BEC to power flight controllers and receivers. The OrangeRX 1045 (10×4.5-inch) propellers are made from high-strength ABS plastic, offering a balanced thrust-to-weight ratio. This set is designed as a plug-and-play solution, with motors pre-soldered with connectors for straightforward integration into a wide range of airframes.

Key Features

  • Complete 4-Motor Propulsion Kit: Includes all necessary components (motors, ESCs, propellers) for a quadcopter build.
  • 1400KV Brushless Motor: Delivers high torque and efficient RPM for endurance and medium-lift applications on 2S-3S LiPo.
  • SimonK 30A ESC with BEC: Provides smooth, responsive speed control and regulated 5V power for onboard electronics.
  • Durable 1045 Propellers: High-strength ABS plastic propellers (10x4.5-inch) offer reliable thrust and are included in CW/CCW pairs.
  • Robust Mechanical Design: Motor features a 3.17mm steel shaft and a solid aluminum case for impact resistance and heat dissipation.
  • Bi-Directional Capability: Motor rotation direction can be reversed electronically, simplifying physical mounting and wiring.
  • Lightweight Construction: Motor weight of 62 grams each contributes to an optimized overall power-to-weight ratio for the aircraft.

Applications

  • DIY Quadcopter & Hexacopter Builds: Ideal propulsion core for custom 450-550mm frame size multirotors for aerial photography or training.
  • Endurance & Long-Range FPV Platforms: The 1400KV efficiency suits fixed-wing UAVs or multirotors optimized for extended flight time on 3S packs.
  • RC Airplane Power Systems: Provides reliable thrust for trainer and sport fixed-wing aircraft requiring a 30A ESC system.
  • Educational & Prototyping Projects: A complete, cost-effective component set for university UAV teams or hobbyists learning multirotor assembly.
  • Light-Lift Cargo & Payload Drones: Suitable for small-scale UAVs designed to carry lightweight sensors or payloads within a 2S-3S power envelope.

Technical Specifications

Motor ModelA2212 10T/13T
KV Rating1400 KV
Motor TypeOutrunner Brushless
Compatible Battery2S to 3S LiPo
Max Current (60s)16A
No-Load Current (@10V)0.7A
Max Efficiency Current6-12A
Poles14
Shaft Diameter3.17 mm
Motor Dimensions (WxL)26.5 x 27.5 mm
Motor Weight62 g
ESC ModelSimonK 30A
ESC BECOn-Board Switching BEC
Propeller ModelOrangeRX 1045 (10x4.5)
Propeller MaterialABS Plastic
Propeller Configuration1CW + 1CCW per pair
Package Contents4x Motor, 4x ESC, 4x Propeller Pair, 4x Accessory Kit

Frequently Asked Questions

What is the input voltage range for this A2212 motor and ESC combo?

The A2212 1400KV motors paired with the SimonK 30A ESCs are designed for 2S to 3S LiPo battery packs (7.4V - 11.1V nominal). Exceeding 3S (12.6V fully charged) may damage the ESCs and overheat the motors. Always verify your battery voltage matches this range before flight.

Can I use these motors with a 4-in-1 ESC or must I use the included individual ESCs?

These motors are standard 3-wire brushless units and are compatible with any ESC matching their current and voltage specs. The included individual SimonK 30A ESCs are provided for convenience and feature an integrated BEC. You can use a 4-in-1 ESC rated for at least 30A per channel and 2S-3S input, but you would not use the BEC from the individual ESCs in that configuration.

How do I set the motor rotation direction (CW/CCW) for my quadcopter?

These motors are bi-directional. To change rotation, simply swap any two of the three motor wires connected to the ESC. The SimonK firmware does not require a dedicated BLHeli configurator for this basic change. Ensure your flight controller software (Betaflight, iNav) is configured with the correct motor mapping after physically installing them.

What size quadcopter frame are these A2212 1400KV motors best suited for?

With the included 1045 (10-inch) propellers, this motor combo is optimally suited for quadcopter frames in the 450mm to 550mm diagonal wheelbase class. This size is typical for beginner builds, aerial photography platforms, and endurance-focused drones where efficient thrust is prioritized over extreme acrobatic performance.

Does the SimonK 30A ESC support modern firmware like BLHeli_S or Bluejay?

No, the included SimonK ESCs run the older SimonK firmware, which does not support features like RPM filtering, bidirectional DShot, or the Bluejay configurator. They provide reliable, basic PWM and Oneshot125 protocol support. For advanced features, you would need to replace them with a modern BLHeli_32 or BLHeli_S based ESC.

Package Includes

  • 4 x A2212 1400KV Brushless Motor with Soldered Connectors
  • 4 x SimonK 30A BLDC Electronic Speed Controller (ESC)
  • 4 x Pairs of OrangeRX 1045 (10x4.5) ABS Propellers (1CW+1CCW each)
  • 4 x Sets of Motor Mounting Accessories (Screws, Bullet Connectors, etc.)

Additional Information

Weight 0.355 kg
Dimensions 8 × 12 × 5 cm
