DYS D2225-15 1600KV Brushless Motor
The DYS D2225-15 is a 1600KV brushless outrunner motor designed for medium-sized quadcopters and multirotors, operating on 2-3S LiPo voltage (7.2V-11.1V). It delivers up to 90W of power and 440g of thrust per motor when paired with efficient 8-10 inch propellers and an 18A ESC.
Features
- 1600KV rating optimized for 2-3S LiPo batteries (7.2V-11.1V).
- Delivers up to 90W max power and 440g of thrust per motor with compatible propellers.
- Features a 3.175mm (3mm) shaft diameter and M3 mounting pattern for secure installation.
- Pre-soldered bullet connectors simplify wiring to compatible 18A ESCs.
- Lightweight 32g design balances performance and efficiency for medium-sized builds.
Out of stock
The DYS D2225-15 brushless motor is engineered for reliable propulsion in medium-scale multirotor applications. Its 1600KV winding is specifically tuned for 2-3S LiPo power systems, providing a balanced combination of torque and rotational speed ideal for efficiency-focused builds. The outrunner design offers direct cooling and robust power delivery.
Constructed with a steel housing and shaft, the motor is built to withstand the vibrational stresses of aerial flight. The integrated bullet connectors reduce assembly time and ensure a reliable electrical connection to standard electronic speed controllers. With a maximum power handling of 90W, it is a capable choice for pilots seeking a high-value propulsion solution.
Additional Information
| Weight | 0.042 kg |
|---|---|
| Dimensions | 11 × 5 × 4 cm |
