DYS D2225-19 1350KV Brushless Motor
The DYS D2225-19 is a 1350KV brushless outrunner motor designed for medium-sized multirotor drones and RC aircraft, compatible with 2S to 3S LiPo batteries and 20A ESCs. It delivers up to 340g of thrust per motor with a 10-inch propeller, offering a balance of power and efficiency for long-range and endurance-focused builds.
Features
- 1350KV rating optimized for 2S-3S LiPo operation and 10-inch propellers.
- Delivers up to 340g of thrust per motor for efficient medium-sized quadcopter builds.
- Features a 3.175mm x 41mm shaft and pre-soldered banana connectors for simplified ESC integration.
- 80W maximum power handling with a lightweight 32g design for improved flight endurance.
- Ideal for long-range FPV, aerial photography, and general multirotor applications.
Out of stock
The DYS D2225-19 brushless motor is engineered for reliable propulsion in medium-sized multirotor platforms. Its 1350KV winding is specifically tuned for 2S to 3S LiPo voltage ranges, providing a smooth and efficient power curve that maximizes flight time when paired with larger 10-inch propellers. The outrunner design ensures effective cooling and consistent torque delivery across the throttle range.
Constructed with a durable steel housing and a precision-balanced rotor, this motor is built to withstand the vibrations and operational stresses of extended flight sessions. The integrated 3.175mm shaft and pre-attached bullet connectors simplify the build process, allowing for direct solderless connection to compatible 20A electronic speed controllers, reducing setup time and potential failure points.
Additional Information
| Weight | 0.042 kg |
|---|---|
| Dimensions | 11 × 5 × 4 cm |
