DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion
DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion - Image 2
DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion - Image 3
DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion - Image 4
DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion - Image 5
SKU: IOWC-1396
📋 GST Invoice Available

DFRobot Beetle ESP32-C3 RISC-V Dev Board w/ Expansion

₹1,009.00 (Inclusive of all taxes)
Out of Stock

The DFRobot Beetle ESP32-C3 is a compact, RISC-V powered development board featuring dual-mode Wi-Fi & Bluetooth 5 (LE) connectivity, onboard lithium battery charging, and an included expansion board for simplified project integration and screen interfacing.

Features

  • Compact RISC-V Core: Features the ESP32-C3’s 32-bit single-core RISC-V processor on a tiny 25 x 20.5 mm footprint.
  • Dual-Mode Wireless: Supports Wi-Fi and Bluetooth 5 (LE) connectivity, including Bluetooth Mesh and Espressif Wi-Fi Mesh protocols.
  • Integrated Power Management: Onboard lithium battery charging circuit allows direct connection of Li-ion cells with safe charging/discharging.
  • Expanded Connectivity: Includes an expansion board that provides additional power pins and an easy-to-connect GDI interface for screens.
  • Versatile Development: Programmable via Arduino IDE, ESP-IDF, and MicroPython, with extensive GPIO breakout for sensors and actuators.

Out of stock

Description

The DFRobot Beetle ESP32-C3 is a highly integrated IoT development board built around Espressif’s ESP32-C3 RISC-V microcontroller. Its coin-sized design packs 13 GPIO pins, ensuring ample I/O for sensor networks and actuator control without sacrificing project footprint. The integrated power management subsystem includes a dedicated Li-ion battery charger, enabling the creation of portable, battery-powered wireless nodes with optimized energy efficiency.

Engineered for reliable wireless communication, the board establishes robust connections using Wi-Fi and Bluetooth 5 Low Energy. Support for mesh networking protocols extends coverage and stability for distributed IoT deployments. The accompanying expansion board simplifies physical interfacing by providing additional power rails and a dedicated connector for displays, reducing wiring complexity during system integration. This board is ideal for developers seeking a compact, full-featured platform for smart home automation, wearable tech, and industrial telemetry projects.

Key Features

  • Ultra-Compact Form Factor: Measures only 25 x 20.5 mm, ideal for space-constrained embedded applications and wearable devices.
  • Onboard Battery Charging: Integrated lithium battery charge management circuit supports direct Li-ion cell connection with a 400mA max charging current.
  • Comprehensive Wireless Support: Enables Wi-Fi and Bluetooth 5 (LE) dual-mode communication, with compatibility for both Bluetooth Mesh and Espressif Wi-Fi Mesh.
  • Enhanced Expansion: Included expansion board breaks out additional power sources and features a GDI interface for easy connection to displays.
  • Multi-Framework Development: Fully programmable using popular frameworks including Arduino IDE, ESP-IDF, and MicroPython (C/Python).
  • Extensive I/O Breakout: 13 GPIO pins accessible from the small board, providing flexibility for connecting sensors, LEDs, and other peripherals.
  • IoT Platform Ready: Supported by tutorials for connecting to major IoT platforms like Aliyun and IFTTT for cloud integration.

Applications

  • Compact IoT Sensor Nodes: For environmental monitoring, smart agriculture, and industrial telemetry.
  • Wearable & Portable Electronics: In fitness trackers, personal locators, and battery-operated gadgets.
  • Smart Home Automation: As a central controller or end-node for lights, switches, and sensors.
  • Prototyping & Education: An accessible platform for learning embedded systems and wireless communication.
  • Mesh Network Devices: Building reliable, extended-coverage networks for asset tracking and building automation.

Technical Specifications

Microcontroller / SoCESP32-C3 (32-bit RISC-V Single-Core)
Wireless ProtocolsWi-Fi, Bluetooth 5 (LE), Bluetooth Mesh, Espressif Wi-Fi Mesh
Bluetooth Data Rate125 Kbps, 500 Kbps, 1 Mbps, 2 Mbps
Supply Voltage3.3V (Operating), 5V DC (Type-C & VIN Input)
Operating Current25mA (Max)
Charging Current400mA (Max)
Interfaces13x GPIO, Type-C USB, Battery Input, GDI (via expansion board)
Dimensions25 x 20.5 mm
Development FrameworksArduino IDE, ESP-IDF, MicroPython

Frequently Asked Questions

How do I program the DFRobot Beetle ESP32-C3?

You can program the board using the Arduino IDE with the ESP32 board package installed, Espressif's official ESP-IDF framework for full control, or MicroPython for Python-based scripting. Connect via the onboard USB Type-C port, select the correct board (e.g., ESP32-C3 DevModule), and upload your code. Ensure you have the latest USB drivers if needed.

Can I power this board with a battery?

Yes, the board features an integrated lithium battery charging circuit. You can directly connect a 3.7V Li-ion or LiPo cell to the designated battery pins. The onboard charger manages safe charging up to 400mA when USB power is present, and the system operates from the battery's power when USB is disconnected.

What is the purpose of the included expansion board?

The expansion board provides easier access to power pins (5V, 3.3V, GND) and includes a GDI (General Display Interface) connector, simplifying wiring for displays like TFT screens. It makes prototyping cleaner and more convenient without soldering directly to the small main board's pins.

Does this board support Bluetooth Mesh networking?

Yes, the Beetle ESP32-C3 supports both Bluetooth 5 (LE) and the Bluetooth Mesh protocol, allowing you to create large-scale, reliable networks of devices. It also supports Espressif's proprietary Wi-Fi Mesh, giving you flexible options for extending wireless coverage in IoT deployments.

Package Includes

  • 1 x DFRobot Beetle ESP32-C3 (RISC-V Core Development Board)
  • 1 x Expansion Board

Additional Information

Weight 0.05 kg
Dimensions 7 × 5 × 4 cm
