AxisFlying 5.8G 3W Analog Video Transmitter (VTX)
The AxisFlying 5.8G 3W Analog VTX is a high-power video transmitter designed for FPV drones, offering stable, long-range video transmission on the 5.8 GHz band with a wide 7-36V DC input range for compatibility with 2S to 6S LiPo battery systems.
Features
- High 3000mW (3W) output power for extended range and signal penetration.
- Wide 7-36V DC input voltage range compatible with 2S to 6S LiPo batteries.
- Compact, lightweight design (27.5g) with integrated heat sink for thermal management.
- Supports NTSC/PAL video formats with multiple channel selection.
- Features an MMCX antenna connector for secure, low-loss RF connections.
Out of stock
The AxisFlying 5.8G 3W Analog Video Transmitter delivers robust RF performance for FPV pilots requiring reliable, long-distance video feeds. Its 3-watt output ensures a strong, clear signal capable of penetrating obstacles and maintaining low-latency video links essential for racing and long-range exploration. The integrated heat sink and efficient power design manage thermal loads during continuous high-power operation.
Engineered for seamless integration, the VTX accepts a broad 7-36V DC input, making it a versatile choice for builds ranging from lightweight 2S micro drones to powerful 6S freestyle and long-range platforms. Its compact footprint and MMCX antenna interface allow for flexible mounting in tight frame layouts while maintaining a durable and reliable RF connection.
Additional Information
| Weight | 0.0275 kg |
|---|---|
| Dimensions | 5.379 × 2.78 cm |
